| Ref | Part Number | Description |
|---|
| 1 |
513033025 |
Fuel Tank Cap This part replaces 572039600. |
| 2 |
420922242 |
Angular Tube This part replaces 290922245. |
| 3 |
219704462 |
ADHESIVE LOCTITE 515 50ML - Call your local BRP dealership |
| 4 |
278001401 |
OIL LEVER SENSOR ASS'Y - Call your local BRP dealership |
| 5 |
293650170 |
Tridon Gear Clamp This part replaces 293650038. |
| 6 |
293650042 |
Oetiker Clamp |
| 7 |
293750003 |
TIE RAP MOUNT - Call your local BRP dealership |
| 8 |
293750002 |
Tie Wrap 142 mm |
| 9 |
275000138 |
Oil Tank |
| 10 |
707800347 |
Grommet This part replaces 570273900. |
| 11 |
709200285 |
Grommet This part replaces 570135100. |
| 12 |
414523600 |
Elbow Fitting This part replaces 293710002. |
| 13 |
414650200 |
Elbow Fitting 90 Deg |
| 14 |
293150016 |
Rivet 1/8" |
| 15 |
275000051 |
OIL FILTER - Call your local BRP dealership |
| 16 |
219704412 |
Polyurethane Hose, 8 Mm 3000Mm Long |
| 17 |
219704356 |
Was 275500008 Hose 12 mm |
| 18 |
219704414 |
Was 415110000 Polyurethane Hose 5.2 mm |
| 19 |
275500398 |
Check Valve |
| 20 |
293850022 |
STRAP - Call your local BRP dealership |
| 21 |
293750001 |
Tie Wrap 94 mm |
| 22 |
204550028 |
SLIT CONDUIT, METER - Call your local BRP dealership |
