| Ref | Part Number | Description |
|---|
| M5142865 |
LH |
RUNNER ASS?Y - Call your local BRP dealership M5142865 |
| M5142865 |
Rail |
GA Ass. - Appelez votre concessionnaire BRP local M5142865 |
| M538793 |
Attache |
GA M538793 |
| M538793 |
LH |
Support M538793 |
| 1 |
M5142866 |
RH Runner Ass’Y |
| 2 |
M548387 |
Washer |
| 3 |
207064044 |
Hex. Screw M6 X 40 This part replaces M40002. |
| 4 |
207181644 |
Hex. Screw M8 x 16 This part replaces 222081665. |
| 6 |
293370056 |
Circlip 20X1.75 DIN471 This part replaces M31007. |
| 7 |
503190797 |
Wheel 135 This part replaces 570066622. |
| 8 |
234082410 |
Flat Washer 8 mm This part replaces M20010. |
| 9 |
40336 |
HEX. SCREW M8 X 20 - Call your local BRP dealership This part replaces M40336. |
| 10 |
M539653 |
Axle |
| 11 |
M538794 |
RH Support |
| 13 |
503189534 |
Cushion This part replaces 415112700. |
| 14 |
549695 |
Shaft This part replaces M549695. |
| 16 |
293350115 |
Ball Bearing This part replaces 405404500. |
| 17 |
M549582 |
Runner Shoe |
| 18 |
207162144 |
Hex. Screw M6 x 20 |
| 19 |
234061410 |
Flat Washer 6 mm This part replaces M20003. |
| 20 |
605348954 |
Runner Protector This part replaces M534578. |
| 21 |
207162544 |
Hex. Screw M6 X 25 This part replaces 222062565. |
| 23 |
M549718 |
Cross Shaft |
| 24 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 This part replaces M33200. |
| 25 |
234001410 |
Flat Washer 10 mm This part replaces M20005. |
| 26 |
570023100 |
RUBBER STOPPER - Call your local BRP dealership |
| 27 |
232581414 |
Hex. Elastic Stop Nut M8 |
| 28 |
M548841 |
Sleeve |
| 30 |
M5440313 |
Sleeve |
| 31 |
M41035 |
Circlip |
| 32 |
M5441643 |
Bolt-Eye Adjuster |
| 33 |
M5441645 |
Pin |
| 34 |
572034000 |
ADJUSTER KNOB - Call your local BRP dealership |
| 35 |
M548469 |
Plate Support |
| 36 |
5442604 |
STOPPER STRAP - Call your local BRP dealership This part replaces M5442604. |
| 37 |
414460600 |
SPRING - Call your local BRP dealership |
| 38 |
233601416 |
Elastic Locking Nut M10 X 1.5 This part replaces 228501045. |
| 39 |
548799 |
Spring Roller This part replaces M548799. |
| 40 |
M549680 |
Support Shaft |
| 41 |
M544212 |
RIVET - Call your local BRP dealership |
| 42 |
5345454 |
SHAFT - Call your local BRP dealership This part replaces M539655. |
| 43 |
538805 |
Spring L.H. This part replaces M538805. |
| 44 |
31023 |
Bearing This part replaces M31046. |
| 45 |
23133 |
SHOCK - Call your local BRP dealership This part replaces M23016. |
| 46 |
544417 |
Shock Spacer - Call your local BRP dealership This part replaces M544417. |
| 47 |
207005044 |
Hex. Screw M10 X 1.5 X 50 This part replaces 222005065. |
| 49 |
31001 |
Retaining Ring 25X2 Din471(1=10Pcs) This part replaces M31001. |
| 52 |
293350115 |
Ball Bearing This part replaces 405404500. |
| 53 |
207161044 |
HEX. SCREW M6 X 10 - Call your local BRP dealership This part replaces 222061065. |
| 54 |
234061410 |
Flat Washer 6 mm This part replaces M20003. |
| 55 |
572030800 |
LH ADJUST CAM - Call your local BRP dealership |
| 56 |
293350115 |
Ball Bearing This part replaces 405404500. |
| 57 |
31002 |
Retaining Ring (1=10Pcs) This part replaces M31002. |
| 58 |
542770 |
Shaft Sleeve This part replaces M542770. |
| 60 |
293800005 |
Loctite 271, 10 ml |
| 62 |
549656 |
Swing shaft - Call your local BRP dealership This part replaces M549656. |
| 65 |
207004044 |
Hex. Screw M10 X 40 This part replaces M40014. |
| 68 |
545758 |
Spacer This part replaces M545758. |
| 69 |
5440350 |
Crank Arm R.H. This part replaces M5440350. |
| 72 |
207084544 |
Hex. Screw M8 X 45 This part replaces M40008. |
| 73 |
535455 |
Rubber Stopper - Call your local BRP dealership This part replaces M535455. |
| 74 |
5440645 |
Adjustment Plate This part replaces M5440645. |
| 75 |
5440349 |
Crank Arm Lh This part replaces M5440349. |
| 77 |
M541815 |
Sleeve |
| 78 |
541816 |
Axle This part replaces M541816. |
| 79 |
539672 |
Support For Rearaxle Lh This part replaces M539672. |
| 80 |
539673 |
Support For Rearaxle Rh This part replaces M539673. |
| 81 |
5440377 |
BOLT-EYE ADJUSTER - Call your local BRP dealership This part replaces M5440377. |
| 82 |
25004 |
Cup Spring This part replaces M25004. |
| 84 |
605251783 |
EXTENSION TUBE LH - Call your local BRP dealership This part replaces M5243223. |
| 85 |
232006414 |
Hex. Nut M10 X 1.5 This part replaces M33004. |
| 86 |
207162044 |
Hex. Screw M6 X 20 |
| 87 |
M548262 |
Protector |
| 88 |
M40239 |
SCREW - Call your local BRP dealership |
| 90 |
546668 |
Spacer - Call your local BRP dealership This part replaces M546668. |
| 91 |
605251784 |
EXTENSION TUBE RH - Call your local BRP dealership This part replaces M5243222. |
| 93 |
40314 |
Hex Sc. M10x 30 BN73 m8.8 MUP(1=10pcs) - Call your local BRP dealership This part replaces M40314. |
| 94 |
570066722 |
BOND WHEEL 165 - Call your local BRP dealership |
| 95 |
234002410 |
Flat Washer 10 mm This part replaces M20011. |
| 96 |
40335 |
Hex Sc. M10X 30 Bn73 M8.8 Zne(1=10Pcs) This part replaces M40335. |
| 97 |
M546577 |
Sleeve |
| 538806 |
Ressort |
R.H. This part replaces M538806. 538806 |
| 538806 |
Spring |
R.H. This part replaces M538806. 538806 |
| 5342228 |
Ressort |
R.H. This part replaces M5342228. 5342228 |
| 5342228 |
Spring |
R.H. This part replaces M5342228. 5342228 |
| 5342229 |
Ressort |
L.H. This part replaces M5342229. 5342229 |
| 5342229 |
Spring |
L.H. This part replaces M5342229. 5342229 |
| 572030900 |
Came |
De Réglage Droit - Appelez votre concessionnaire BRP local 572030900 |
| 572030900 |
RH |
ADJUST CAM - Call your local BRP dealership 572030900 |
