| Ref | Part Number | Description |
|---|
| 1 |
1018565002 |
CASE |
| 2 |
0000444687 |
PIPE PLUG, 1/8-27 |
| 3 |
0000444866 |
PIPE PLUG, 3/8-18 |
| 4 |
0A4740G |
BREATHER |
| 5 |
072C-98 |
OIL INLET SHIELD |
| 6 |
035-143 |
FLAT WASHER |
| 7 |
05L-222 |
SPRING |
| 8 |
71B-140 |
OIL BAFFLE |
| 9 |
1000191002 |
PLUG, 3/8-18 |
| 10 |
71B-140 |
OIL BAFFLE |
| 11 |
1017193001 |
THRUST WASHER |
| 12 |
1018659014 |
PINION CARRIER ASSEMBLY |
| 13 |
0A4877D |
BUSHING |
| 14 |
04806B |
SEALING RING |
| 15 |
71C-2A16 |
DRIVE GEAR ASSEMBLY |
| 17 |
1017559001 |
DIPSTICK |
| 18 |
1004034002 |
DIPSTICK TUBE |
| 20 |
9418892 |
HEX NUT, 5/16-24 |
| 21 |
0000108579 |
LOCK WASHER, 5/16 |
| 22 |
0000103340 |
FLAT WASHER, 5/16 |
| 23 |
0000453632 |
STEEL BALL, 5/16 |
| 24 |
071-42 |
POPPET SPRING |
| 25 |
1000640004 |
NEUTRAL SWITCH ASSEMBLY |
| 26 |
NEUTRAL |
SWITCH |
| 27 |
1000141046 |
O-RING |
| 28 |
1016039001 |
SWITCH CAM |
| 29 |
0000179796 |
HEX HEAD BOLT, 1/4-20 x 1/2 |
| 30 |
0000103319 |
LOCK WASHER, 1/4" |
| 31 |
1016039001 |
SWITCH CAM |
| 32 |
071-14 |
VALVE COVER GASKET |
| 33 |
71-A244A |
CONTROL VALVE ASSEMBLY |
| 34 |
04821 |
SNAP RING |
| 35 |
071-246 |
SPRING RETAINER |
| 36 |
071-242 |
VALVE SPRING |
| 37 |
071-243 |
REGULATOR VALVE |
| 38 |
04804H |
O-RING |
| 39 |
71-244A |
CONTROL VALVE |
| 40 |
71C-A60 |
PUMP ASSEMBLY |
| 41 |
1000183021 |
HEX HEAD BOLT, 3/16-18 x 1 3/8 |
| 42 |
1000044014 |
OIL SEAL |
| 43 |
03-61 |
PUMP GASKET |
| 44 |
04873 |
WOODRUFF KEY |
| 45 |
071C-A8 |
FORWARD & REVERSE ADAPTER ASSY. |
| 46 |
04911 |
CAPSCREW, 3/8-16 x 1 1/4 |
| 48 |
04840D |
NEEDLE BEARING |
| 49 |
71-144B |
GASKET |
| 50 |
0000444858 |
PIPE PLUG, 1/4 |
| 51 |
071-35 |
REVERSE CLUTCH PISTON |
| 52 |
04805A |
CLUTCH SEALING RING |
| 53 |
04804G |
O-RING |
| 54 |
071-71 |
REVERSE CLUTCH PRESSURE PLATE |
| 55 |
072-176 |
STEEL CLUTCH PLATE |
| 56 |
72-A66B |
FRICTION CLUTCH PLATE |
| 57 |
071-97 |
PRESSURE PLATE SPRING |
| 58 |
071-87A |
DOWEL PIN, .312 DIA x .438 LONG |
| 58A |
0R6-177 |
DOWEL PIN, .312 DIA x .621 LONG |
| 58B |
04622E |
DOWEL PIN, .312 DIA x .875 LONG |
| 59 |
1016193001 |
THRUST WASHER |
| 60 |
04822 |
SNAP RING |
| 61 |
04766B |
SNAP RING |
| 62 |
04559A |
SNAP RING |
| 63 |
0B108A |
BEARING |
| 64 |
072-70 |
FORWARD CLUTCH CYLINDER |
| 65 |
071-45 |
FORWARD CLUTCH PISTON |
| 66 |
05M-122 |
O-RING |
| 67 |
05L-36 |
PISTON SEALING RING |
| 68 |
05C-33 |
CLUTCH SPRING BEARING RING |
| 69 |
03-37 |
CLUTCH BELLEVILLE SPRING |
| 70 |
04755 |
SNAP RING |
| 71 |
5C-175A |
CLUTCH PRESSURE PLATE |
| 72 |
03-176 |
STEEL CLUTCH PLATE |
| 73 |
5C-A66A |
FRICTION CLUTCH PLATE |
| 74 |
05L-67 |
CLUTCH PRESSURE PLATE |
| 75 |
04768 |
SNAP RING, .050-.054 THICK |
| 75 |
04768A |
SNAP RING, .074-.078 THICK |
| 75 |
04768B |
SNAP RING, .096-.100 THICK |
| 75 |
1000139018 |
SNAP RING, .062-.066 THICK |
| 76 |
072-6 |
RING GEAR |
| 77 |
071-17 |
THRUST WASHER |
| 78 |
04806J |
SEALING RING |
| 79 |
04495 |
SNAP RING |
| 80 |
1016179001 |
FORWARD CLUTCH HUB |
