02- Fuel System _14Y1503
Parts (47)
| Ref | Part Number | Description |
|---|---|---|
| 2 | 207662044 | Hex. Flange Screw M6 X 20 |
| 3 | 207662544 | Hex. Flange Screw M6 X 25 |
| 4 | 210261250 | Hex. Flange Screw M6 X 12 This part replaces 210261280. |
| 5 | 224060201 | Flat Washer |
| 6 | 232361493 | Domed Nut M6 |
| 7 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 |
| 8 | 250000767 | Torx Truss Screw M6 X 12 This part replaces 250000325. |
| 9 | 250100198 | Panel Nut M6 X 1.0 This part replaces 250100113. |
| 10 | 293150230 | Tuflok Plastic Rivet This part replaces 293150089. |
| 12 | 293650025 | Oetiker Gear Clamp |
| 14 | 293650046 | Oetiker Clamp |
| 15 | 293650047 | Crimp Clamp, 15.3-706R |
| 16 | 293650125 | Oetiker Clamp |
| 17 | 293650186 | Oetiker Clamp |
| 18 | 709000582 | Grommet This part replaces 293720053. |
| 19 | 414115200 | Tie-Rap 180 mm |
| 20 | 414745900 | Tuflock Phillips Plastic Screw |
| 21 | 513033029 | Universal Spring Clamp |
| 22 | 513033047 | Open Clamp |
| 24 | 219704408 | Tubing 16 Mm 1000Mm Long |
| 25 | 709000057 | Open Clamp |
| 26 | 709000090 | Vapor Canister |
| 27 | 219800056 | Fuel Filter Ass'y |
| 27a | 513034047 | Fuel Filter This part replaces 709000100. |
| 28 | 709000443 | Bleed Valve |
| 29 | 709000125 | Female Quick Fitting Ass'y |
| 30 | 709000130 | Carpet |
| 31 | 293710192 | Quick Connect Pipe Fitting This part replaces 709000141. |
| 32 | 709000157 | Reflective Sheet |
| 33 | 709000162 | Bushing |
| 34 | 219800248 | Seal Kit |
| 35 | 709000264 | Fuel Line 7.9 mm, Meter |
| 38 | 709001447 | Fuel Tank This part replaces 219800299. |
| 39 | 709000340 | Reflective Sheet |
| 40 | 709000656 | Hose, 880MM |
| 41 | 709001622 | Hose This part replaces 709000658. |
| 42 | 709000370 | Fuel Pump Module |
| 43 | 293710105 | Elbow Fitting 90° |
| 44 | 709000413 | Rollover Valve |
| 45 | 709000660 | Fuel Cap This part replaces 709000414. |
| 47 | 709000452 | Fuel Filter Support |
| 48 | 219800628 | Kit Y Fitting This part replaces 709000453. |
| 49 | 709000445 | HOSE 6,35MM ID - 680MM - Call your local BRP dealership |
| 51 | 219704612 | Hose 3000Mm Long This part replaces 219704441. |
| 52 | 709000814 | Hose Support This part replaces 709000469. |
| 59 | 709000523 | Formed Hose |
| 60 | 709000524 | Air Filter |
