02- Fuel System
Parts (18)
| Ref | Part Number | Description |
|---|---|---|
| 1 | M519393 | Fuel Tank |
| 2 | 572161200 | Fuel Tank Cap |
| 3 | M544297 | Gasket |
| 4 | 280000674 | Grommet This part replaces M28037. |
| 5 | 533535 | Male Connector This part replaces M533535. |
| 6 | 414865700 | Fuel Filter |
| 7 | Not | Available As Spare Part - Fuel Line |
| 8 | M27086 | Spring Clamp |
| 9 | Not | Available As Spare Part - Fuel Line |
| 10 | 605352516 | Fuel Filter This part replaces M21065. |
| 11 | M28012 | HOUSING - Call your local BRP dealership |
| 12 | Not | Available As Spare Part - Fuel Line |
| 13 | 414420700 | Spring Clamp |
| 14 | 403800800 | FUEL PUMP DF44-226A - Call your local BRP dealership |
| 14A | 404118500 | Screw |
| 14B | 404901600 | Packing (Cap) |
| 14C | 404901700 | Diaphragm |
| 14D | 404901800 | Membrane |
