09- Front Fender
Parts (26)
| Ref | Part Number | Description |
|---|---|---|
| 1 | S46220RCA000 | Shift Lever Cover |
| 2 | S50611RCA000 | Radiator Grille |
| 3 | S61105RCA000 | Grommet |
| 4 | S6110GRCCE00ZY | Yellow Front Fender This part replaces S6110GRCCA00ZY. |
| 4a | S87131RCAA00 | Front Decal |
| 4b | S87136RCAA00T2 | LH FRONT DECAL B - Call your local BRP dealership This part replaces S87136RCAA00. |
| 4c | S87137RCAA00T2 | RH FRONT DECAL B - Call your local BRP dealership This part replaces S87137RCAA00. |
| 4d | S87501RCB900 | Warning Decal A |
| 4e | S87502RCA000 | Warning Decal B |
| 4f | S87505RCAA00 | Shifter Label |
| 5 | S80103X01000 | Rubber Washer |
| 6 | S80104X01000 | Fender Collar |
| 7 | S83520RCA000JF | Fr.Rh.Side Fender This part replaces S83520RCA000. |
| 8 | S83620RCA000JF | LH Pannel |
| 9 | S90302V02000 | Clip Nut |
| 10 | S9390332280 | Tapping Screw M4 X 12 |
| 11 | S38600RA1000 | DC Power Outlet, 12 Volts |
| 12 | S6430GRCAA00JF | Radiator Cover Ass'y |
| 12a | S87130RCAA00T2 | Decal Sd250 This part replaces S87130RCAA00. |
| 12b | S87500RCA000 | BRP Logo |
| 14 | S43020RCA000 | Fuel Tank Cover |
| 15 | S934040601407 | Washer Bolt |
| 16 | S90164RCA000 | Special Screw |
| 17 | S934040602507 | Washer Bolt |
| 18 | S90119G03900 | Screw Washer |
| 19 | S9390335280 | Tapping Screw M5 X 12 |
