| Ref | Part Number | Description |
|---|
| 2500 |
705014333 |
Carbon Black, LH Front Door Panel This part replaces 705012472. |
| 2510 |
705016016 |
Orange Crush, LH Front Door This part replaces 705014089. |
| 2525 |
207582054 |
Hex Screw Washer Head M8 X 20 |
| 2526 |
234081430 |
Flat Washer M8 |
| 2530 |
234081100 |
Flat Washer 8 mm, Nylon |
| 2540 |
705013095 |
LH Latch |
| 2550 |
293850135 |
Belt |
| 2551 |
293150103 |
Pop Rivet 3/16" |
| 2552 |
293900104 |
Bushing |
| 2570 |
705013535 |
LH Latch Cover |
| 2580 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 2585 |
250000721 |
Torx Truss Screw M6 X 16 |
| 2586 |
234062670 |
Stainless Steel Flat Washer |
| 2590 |
293150103 |
Pop Rivet 3/16" |
| 2610 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 2620 |
250000722 |
Torx Screw M6 X 20 |
| 2630 |
224061121 |
Flat Washer |
| 2800 |
705014339 |
Carbon Black, RH Front Door Panel This part replaces 705012473. |
| 2810 |
705014090 |
Orange Crush, RH Front Door |
| 2840 |
705013096 |
RH Latch |
| 2870 |
705013536 |
RH Latch Cover |
| 2940 |
293850129 |
Door Belt |
| 2950 |
293150103 |
Pop Rivet 3/16" |
| 3000 |
705010733 |
RH Lower Door Panel |
| 4100 |
705014105 |
Orange Crush, LH Front Lower Body Panel |
| 4200 |
705014106 |
Orange Crush, LH Lower Body Panel |
| 4210 |
250000722 |
Torx Screw M6 X 20 |
| 4230 |
705016606 |
Insert This part replaces 705010872. |
| 4300 |
705014107 |
Orange Crush, LH Rear Lower Body Panel |
| 4400 |
705014108 |
Orange Crush, RH Rear Lower Body Panel |
| 7300a |
715002903 |
Door Panels |
| 7300b |
704907652 |
LH Side Door Decal |
| 7300b |
704907653 |
RH Side Door Decal |
| 7300c |
705012018 |
Door Seal |
| 7300d |
705012750 |
Black, LH Door Frame |
| 7300d |
705012751 |
Black, RH Door Frame |
| 7300e |
250000902 |
Torx-Truss M/S M6 X 80 |
| 7300f |
233261494 |
Hex. Flange Elastic Nut M6 |
| 7300g |
705202223 |
Offset Washer |
| 7300h |
250000749 |
Torx Truss Screw M6 X 50 |
| 7300j |
234062670 |
Stainless Steel Flat Washer |
| 7300k |
219704364 |
Neoprene Seal (1PAC=3M) |
| 8000 |
705014106 |
Orange Crush, LH Lower Body Panel |
| 8010 |
250200164 |
Flat washer M6 |
| 8020 |
250000807 |
Torx Truss Screw M6 X 25 |
| 8030 |
293150108 |
Pop Rivet 3/16” This part replaces 293150108. |
| 8100 |
705014110 |
Orange Crush, RH Body Panel Guard |
| 8200 |
705012774 |
LH Lateral Structure |
| 8210 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 8220 |
207687044 |
Hex. Flange Screw M8 X 70 |
| 8230 |
705205462 |
Saddle Washer |
| 8240 |
233281464 |
Elastic Flange Nut M8 |
