| Ref | Part Number | Description |
|---|
| 1 |
0986040 |
PETCOCK, Exhaust manifold |
| 2 |
0979803 |
CLAMP |
| 3 |
0912523 |
CAP, Water pump bypass |
| 5 |
0912507 |
HOSE, Water pump |
| 6 |
0984686 |
CLAMP, Elbow to thermostat |
| 7 |
0913615 |
ELBOW, Cylinder head |
| 8 |
0912518 |
HOSE, Elbow to thermostat |
| 9 |
0984686 |
CLAMP, Elbow to thermostat |
| 11 |
3852496 |
LOCK WASHER, Bracket to pump This part replaces 0910320. |
| 12 |
0912494 |
SCREW, Elbow, upper |
| 13 |
0912495 |
SCREW, Elbow, lower |
| 14 |
3852604 |
CLAMP, Exhaust This part replaces 0912667. |
| 16 |
0311390 |
BUSHING |
| 16 |
0912825 |
STUD, Bracket to thermostat housing, lower |
| 18 |
0986521 |
HOUSING, Thermostat. This part replaces 0985470. |
| 19 |
0313416 |
GASKET, Thermostat |
| 20 |
0912478 |
GASKET, Thermostat housing |
| 21 |
0120177 |
L'WASHER, Alternator to brkt |
| 22 |
3853799 |
THERMOSTAT ASSY This part replaces 0982554. |
| 23 |
0914627 |
HOSE,Intake manf. to therm. hsg.. This part replaces 0912519. |
| 24 |
0912480 |
GASKET, Elbow, water outlet |
| 25 |
0912880 |
HOSE, Gimbal to thermostat |
| 25 |
0913280 |
HOSE, Cooler to therm. hsg. |
| 26 |
0913393 |
GASKET, Exhaust manifold |
| 27 |
0979803 |
CLAMP |
| 28 |
3853566 |
BUSHING, Pin This part replaces 0913672. |
| 29 |
0913662 |
OIL PAN |
| 30 |
0912477 |
GASKET, High rise |
| 31 |
HOSE, |
Manifold drain, 13" (330mm) long |
| 32 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 33 |
0985810 |
EXHAUST PIPE, Lower |
| 34 |
0913663 |
PIN EXHAUST FLAP |
| 35 |
0985749 |
EXHAUST SEAL |
| 36 |
0986041 |
EXHAUST MANIFOLD |
| 38 |
0913657 |
CORE PLUG |
| 39 |
3852741 |
HOSE, Exhaust This part replaces 0913591. |
| 40 |
0912504 |
WASHER, Adaptor to engine |
| 41 |
0120177 |
L'WASHER, Alternator to brkt |
| 42 |
0316906 |
SCREW, High rise, long |
| 45 |
0912474 |
STUD, Exhaust manifold, rear |
| 45 |
0913282 |
STUD, Exhaust manifold |
| 46 |
0985597 |
OIL DRAIN TUBE |
| 47 |
3852496 |
LOCK WASHER, Bracket to pump This part replaces 0910320. |
| 48 |
0912506 |
NUT, Exhaust manifold |
| 49 |
0913394 |
RISER |
| 50 |
0315712 |
CORE PLUG |
| 51 |
0984876 |
WATER PUMP |
| 52 |
0912760 |
GASKET, Water pump |
| 53 |
0986383 |
OIL PUMP |
| 54 |
0984625 |
PULLEY, Water pump |
| 55 |
0912509 |
BELT, Alternator |
| 56 |
0914285 |
DOWEL, Oil pump to block |
| 57 |
0912525 |
SCREW, Water pump pulley |
| 59 |
0914286 |
SHAFT, Oil pump |
| 60 |
0912627 |
CLAMP |
| 61 |
0914499 |
SCREEN, Oil pump |
| 62 |
0914289 |
SCREW, Screen to oil pump |
| 63 |
0913017 |
GASKET, Screen to pump |
| 64 |
0914290 |
SCREW, Oil pump to block |
| 65 |
0914288 |
NUT, Oil screen to bearing cap |
| 66 |
0914510 |
BOLT, Oil pan |
| 67 |
0914291 |
BOLT, Oil pan |
| 68 |
0914295 |
BOLT, Water pump to block |
| 69 |
0984624 |
GAUGE, Oil level |
| 70 |
0913364 |
FITTING, Oil drain |
| 72 |
0913661 |
GASKET, Oil drain |
| 73 |
3852609 |
RETAINER, Oil drain This part replaces 0912734. |
| 75 |
0912783 |
WASHER, Fitting |
| 77 |
0912524 |
SCREW, Adaptor to engine, upper |
| 78 |
0914502 |
REINFORCEMENT, Stbd. |
| 78 |
0914503 |
REINFORCEMENT, Port |
| 80 |
0306539 |
BOLT, Distributor |
| 81 |
0120177 |
L'WASHER, Alternator to brkt |
