| Ref | Part Number | Description |
|---|
| 1 |
0305545 |
SLEEVE, Bendix drive |
| 2 |
0020437 |
STOP, Pinion |
| 4 |
0204071 |
WASHER, Pinion |
| 5 |
0204374 |
SLEEVE, Anti-drift spring |
| 6 |
0204376 |
PINION |
| 7 |
0204377 |
SCREW SHAFT |
| 9 |
0204379 |
CAP, Cushion, upper |
| 10 |
0204381 |
CUSHION, Pinion |
| 10 |
517306816 |
Center Hood |
| 11 |
0204378 |
SPACE, Cushion |
| 11 |
250000528 |
Torx Screw M5 X 20 |
| 12 |
0204380 |
CAP, Cushion, lower |
| 12 |
250000958 |
Panel Nut M5 X 0.8 |
| 13 |
0378178 |
GEAR & SHAFT ASSY |
| 13 |
517306079 |
RH Hood Front |
| 14 |
250000528 |
Torx Screw M5 X 20 |
| 15 |
0381582 |
END HEAD , Drive This part replaces 0379973. |
| 15 |
250000958 |
Panel Nut M5 X 0.8 |
| 16 |
0310996 |
O RING |
| 16 |
517306077 |
LH Hood Front |
| 17 |
0204589 |
WASHER, Fibre, 1 32" |
| 17 |
517306831 |
Hood Grill |
| 18 |
0204588 |
WASHER STEEL, .042" |
| 19 |
0379971 |
ARMATURE ASSY |
| 20 |
250000528 |
Torx Screw M5 X 20 |
| 22 |
0379967 |
BRUSH PLATE & HOLDER |
| 23 |
0379966 |
HEAD ASSEMBLY, Commutator end |
| 24 |
0307341 |
BRACKET, Mounting |
| 25 |
0383891 |
SPRING SET This part replaces 0311128. |
| 26 |
0311101 |
THRU BOLT |
| 28 |
0302471 |
W.ASHER, Plain |
| 29 |
0379972 |
FRAME & FIELD |
| 30 |
250000958 |
Panel Nut M5 X 0.8 |
| 32 |
0311001 |
SCREW, Support to engine |
| 33 |
0302479 |
VIS, démarreur vers bloc cylindres-carter |
| 34 |
0309263 |
BOLT, Handle This part replaces 0307342. |
| 35 |
0302471 |
W.ASHER, Plain |
| 36 |
0305851 |
SEAL |
| 37 |
0382959 |
BUSHING & HOUSING |
| 100 |
517307222 |
RH Upper Side Panel |
| 110 |
250000725 |
Screw M4 X 16 |
| 120 |
250000528 |
Torx Screw M5 X 20 |
| 130 |
250000958 |
Panel Nut M5 X 0.8 |
| 150 |
517307518 |
LH Upper Side Panel |
| 160 |
250000725 |
Screw M4 X 16 |
| 170 |
250000528 |
Torx Screw M5 X 20 |
| 180 |
250000958 |
Panel Nut M5 X 0.8 |
| 195 |
517308121 |
Upper Side Panel Cap |
| 200 |
517306573 |
Console Rear |
| 210 |
250000958 |
Panel Nut M5 X 0.8 |
| 220 |
250000587 |
Torx Screw M5 X 26 |
| 230 |
250000587 |
Torx Screw M5 X 26 |
| 240 |
517308182 |
Consoel Foam |
| 245 |
517306602 |
Console Nut |
| 250 |
732610072 |
Push Nut |
| 255 |
706002839 |
O-Ring |
| 260 |
517309451 |
Joint This part replaces 517307197. |
| 330 |
517308072 |
VIPH Adapter |
| 335 |
250000725 |
Screw M4 X 16 |
| 360 |
517306808 |
Switch Hole Cap |
| 600 |
517307441 |
Gauge Support |
| 800b |
517308662 |
Wind Deflector |
| 800c |
732610072 |
Push Nut |
| 800d |
250200024 |
Rubber Washer 5 mm |
| 810 |
517303756 |
Grommet |
| 1095 |
219704371 |
Neoprene Seal 3000Mm Long |
| 1295 |
219704371 |
Neoprene Seal 3000Mm Long |
| 2400a |
415130081 |
Bulb |
| 3200b |
517305779 |
Latch |
| 3200c |
732610072 |
Push Nut |
| 3400b |
517305157 |
Seal Joint |
| 3800 |
517306824 |
Black, Head Lamp Bezel |
| 3810 |
250000528 |
Torx Screw M5 X 20 |
| 3820 |
250000958 |
Panel Nut M5 X 0.8 |
| 0377304 |
0377304 |
STARTER DRIVE ASSEMBLY |
| 0379819 |
0379819 |
STARTER MOTOR ASSY |
