| Ref | Part Number | Description |
|---|
| 1 |
709400661 |
HANDLE BAR COVER - Call your local BRP dealership |
| 2 |
709400481 |
STEERING CLAMP - Call your local BRP dealership |
| 3 |
210261650 |
Hex. Flange Screw M6 X 16 This part replaces 210261680. |
| 4 |
709400483 |
HANDLE BAR - Call your local BRP dealership |
| 6 |
219704461 |
LUBRICANT LOCTITE LB 8150 236ML - Call your local BRP dealership |
| 7 |
293550010 |
Synthetic Grease, 400 G |
| 8 |
293350058 |
BALL BEARING - Call your local BRP dealership |
| 9 |
709400532 |
FLANGE - Call your local BRP dealership |
| 10 |
709400478 |
Steering Clamp |
| 11 |
503190439 |
Washer |
| 13 |
205583034 |
Socket Head Screw, Scotch Grip |
| 15a |
XXX |
Not Available As Spare Parts |
| 16 |
210251180 |
HEX. FLANGED SCREW M5 X 11 - Call your local BRP dealership |
| 17 |
709400516 |
HANDLE GRIP - Call your local BRP dealership |
| 18 |
709400517 |
THROTTLE HANDLE - Call your local BRP dealership |
| 19 |
293800100 |
Loctite 406, 7 Oz |
| 20a |
709400189 |
END-PIECE - Call your local BRP dealership |
| 20b |
XXX |
Not Available As Spare Parts |
| 21 |
205082044 |
Socket Head Screw M8 X 20 |
| 22 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 23 |
234081430 |
Flat Washer M8 |
| 25 |
709400551 |
PROTECTOR - Call your local BRP dealership |
| 26 |
207582044 |
Hex. Flange Screw M8 X 20, Scotch Grip |
| 27 |
219704461 |
LUBRICANT LOCTITE LB 8150 236ML - Call your local BRP dealership |
| 28 |
709400469 |
ARM - Call your local BRP dealership |
| 29 |
706200281 |
Hardened Washer This part replaces 250200086. |
| 30 |
250000047 |
Hex. Flange Elastic Nut M12 |
| 31 |
293200113 |
Seal Ring |
| 32 |
709400455 |
SENSOR SUPPORT - Call your local BRP dealership |
| 33 |
207562034 |
Hex. Flange Screw M6 X 20, Scotch Grip |
| 34 |
709400557 |
TIE ROD ASS`Y - Call your local BRP dealership |
| 35 |
706200281 |
Hardened Washer This part replaces 250200086. |
| 36 |
505071711 |
KNUCKLE RH - Call your local BRP dealership |
| 37 |
505071709 |
KNUCKLE LH - Call your local BRP dealership |
| 38 |
250100099 |
Nut M12 |
| 39 |
250400034 |
Cotter Pin |
| 40 |
706200528 |
UPPER SUPPORT - Call your local BRP dealership |
| 41 |
207503534 |
SCREW-HEX.FLANGE DIN.6921 S.GRIP - Call your local BRP dealership |
| 42 |
207583086 |
Hex. Flange Screw M8 X 30, Scotch Grip |
| 43 |
233281416 |
Hex. Elastic Flange Nut M8 |
| 44 |
709400454 |
BELLOWS - Call your local BRP dealership |
| 45 |
414115200 |
Tie-Rap 180 mm |
| 46 |
709400572 |
SHIM - Call your local BRP dealership |
| 47 |
210262050 |
Hexagonal Head Screw This part replaces 210262080. |
