| Ref | Part Number | Description |
|---|
| 7a |
707000995 |
Pressure And Temperature Sensor |
| 7b |
207662554 |
Hex. Flange Screw M6 X 25 |
| 7c |
250100198 |
Panel Nut M6 X 1.0 |
| 7d |
707000586 |
Foam Filter |
| 100b |
709000582 |
Grommet |
| 100c |
250100208 |
Panel Nut M6 X 1.0 |
| 100d |
250000958 |
Panel Nut M5 X 0.8 |
| 100f |
414916600 |
Black, Nylon Cap |
| 500b |
709000582 |
Grommet |
| 500c |
250100208 |
Panel Nut M6 X 1.0 |
| 500d |
250000958 |
Panel Nut M5 X 0.8 |
| 500f |
414916600 |
Black, Nylon Cap |
| 530 |
207663054 |
Hex. Flange Screw M6 X 30 |
| 540 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 545 |
708200405 |
Front Skid Plate |
| 550 |
207662044 |
Hex. Flange Screw M6 X 20 |
| 560 |
207682544 |
Hex. Flange Screw M8 X 25 |
| 565 |
234082430 |
Flat Washer M8 |
| 570 |
233281434 |
Hex. Flange Elastic Nut M8 |
| 1500 |
708200860 |
LH Side Vent |
| 1600 |
708200859 |
RH Side Vent |
| 1650 |
293150230 |
Tuflok Plastic Rivet |
| 2000 |
708200362 |
Front Air Duct Module |
| 2050 |
293150230 |
Tuflok Plastic Rivet |
| 2051 |
293150230 |
Tuflok Plastic Rivet |
| 2450 |
708200493 |
LH Front Union Link |
| 2455 |
293150230 |
Tuflok Plastic Rivet |
| 2460 |
708200494 |
RH Front Union Link |
| 2465 |
293150230 |
Tuflok Plastic Rivet |
| 2500b |
250000958 |
Panel Nut M5 X 0.8 |
| 2550 |
207662044 |
Hex. Flange Screw M6 X 20 |
| 2555 |
293150230 |
Tuflok Plastic Rivet |
| 2560 |
210262050 |
Hexagonal Head Screw |
| 2580 |
705000321 |
Oval Washer |
| 2590 |
705003911 |
Spring |
| 2600 |
705007379 |
Latch |
| 2610 |
207663544 |
Hex. Flange Screw M6 X 35 |
| 2620 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 2630 |
517305742 |
Hood Cable |
| 3000h |
234051670 |
Flat Washer M5 |
| 3100h |
234051670 |
Flat Washer M5 |
| 3150 |
250000578 |
Torx Truss Screw M5 X 16, T25 |
| 3500a |
708200957 |
Front Storage Bin |
| 3500b |
708200490 |
Heat Shield Sheet |
| 3500c |
705006633 |
Stopper |
| 3550 |
293150230 |
Tuflok Plastic Rivet |
| 4000a |
708201237 |
Manta Green, Hood |
| 4000b |
250000958 |
Panel Nut M5 X 0.8 |
| 4000c1 |
232581200 |
Hex. Elastic Nut M8 Brass |
| 4000d |
234082410 |
Flat Washer 8 mm |
| 4000f |
232180600 |
Hex. Jam Nut M8 |
| 4000g |
705002223 |
Lug |
| 4000h |
219704371 |
Neoprene Seal 3000 mm Long |
| 4000j |
219704424 |
Vinyl Tubing, Low Temp 3000Mm Long |
| 4060 |
250000578 |
Torx Truss Screw M5 X 16, T25 |
| 4070 |
234051670 |
Flat Washer M5 |
| 4500a |
708201238 |
Manta Green, LH Front Fairing |
| 4500b |
705006634 |
Polyurethane Stopper |
| 4500c |
293830143 |
Rubber Pad |
| 4600a |
708201239 |
Manta Green, RH Front Fairing |
| 4600b |
705006634 |
Polyurethane Stopper |
| 4650 |
293150230 |
Tuflok Plastic Rivet |
| 4660 |
293150230 |
Tuflok Plastic Rivet |
| 4680 |
250000715 |
Torx Truss Screw M5 X 20 |
| 5000a |
708201236 |
Manta Green, Front Fascia |
| 5000b |
705006633 |
Stopper |
| 5040 |
293150230 |
Tuflok Plastic Rivet |
| 5050 |
250000715 |
Torx Truss Screw M5 X 20 |
| 5051 |
234051670 |
Flat Washer M5 |
| 5052 |
293150230 |
Tuflok Plastic Rivet |
| 5500a |
705009339 |
Molded Frame |
| 5500b |
705009340 |
Front Grille |
| 5500c |
708200937 |
Grille |
| 5500d |
705009952 |
Black, Grille Trim |
| 5500f |
705010273 |
Mounting Plate |
| 5500g |
705004838 |
Flat Clip |
| 5550 |
250000732 |
Torx Screw Nylon |
