08- Rear Suspension Shocks 69 Ranger - Lower section
Parts (48)
| Ref | Part Number | Description |
|---|---|---|
| 10 | 503194824 | Runner |
| 20 | 503194307 | Black, Slider Shoe |
| 30 | 208562531 | Phillips Screw M6 X 25 |
| 40 | 232561414 | Elastic Stop Nut M6 |
| 60 | 503192889 | Front Wheel Shaft |
| 70a | 503190396 | Ball Bearing |
| 80 | 205504544 | Socket Screw |
| 90 | 234001410 | Flat Washer 10 mm |
| 130 | 503193504 | Rubber Stopper |
| 150 | 293150224 | Rivet Pop 3/16 |
| 160 | 503191273 | Washer |
| 195 | 233261466 | Hex. Flanged Elastic Nut M6 |
| 200 | 570023100 | RUBBER STOPPER - Call your local BRP dealership |
| 205 | 207664554 | Hex, Flange Screw |
| 210 | 207667056 | Hex. Flange Screw M6 x 70 |
| 240a | 503190396 | Ball Bearing |
| 245a | 503190396 | Ball Bearing |
| 245b | 415129371 | Retaining Ring |
| 250 | 503193894 | Casted Support |
| 260 | 503191820 | Wheel Cup M6 |
| 280 | 233261466 | Hex. Flanged Elastic Nut M6 |
| 310 | 207662556 | Hex. Flange Screw M6 X 25 |
| 320 | 233261466 | Hex. Flanged Elastic Nut M6 |
| 650 | 503193182 | Lower Support, Center Shock |
| 660 | 250001026 | Screw-Hex.Flange DIN.6921 |
| 670 | 232500416 | Elastic Stop Nut M10 |
| 820 | 205504544 | Socket Screw |
| 835 | 234001410 | Flat Washer 10 mm |
| 1150a | 503190396 | Ball Bearing |
| 1150b | 415129371 | Retaining Ring |
| 1160 | 503191741 | Wheel 200, Black |
| 1170 | 503193352 | Rear Shaft |
| 1190 | 250000817 | Hex Screw With Nilon Patch, M10 X 35 |
| 1200 | 503190428 | Rear Wheel Spacer |
| 1210 | 503190682 | Labyrinth seal |
| 1215 | 503193631 | Support Pipe |
| 1220 | 503190439 | Washer |
| 1223 | 503193250 | Spacer |
| 1224 | 233261466 | Hex. Flanged Elastic Nut M6 |
| 1225 | 207063054 | Hex. Cap Screw M6 X 30 |
| 1226 | 230100044 | HEX. SCREW M10 X 100 - Call your local BRP dealership |
| 1227 | 503192583 | Tensioner |
| 1229 | 233601466 | Elastic Locking Nut M10 |
| 3360 | 503192927 | Shaft Passivated |
| 3370 | 205504544 | Socket Screw |
| 3380 | 234001410 | Flat Washer 10 mm |
| 3385 | 503192771 | Black, Wheel Cap |
| 3390 | 503195345 | Black, Wheel Cap |
