| Ref | Part Number | Description |
|---|
| 10aa |
518325973 |
RH Rear Base |
| 10ab |
518325974 |
LH Rear Base |
| 10ae |
518326656 |
Seal |
| 10af |
518327105 |
Rear Cap |
| 10ah |
390909200 |
Avex Rivet |
| 10aj |
293730042 |
Full Moon Dart 5 mm |
| 10am |
390909100 |
Avex Rivet |
| 10an |
293150144 |
Stavex Rivet |
| 10ap |
293150146 |
Henrob Rivet |
| 10aq |
293150174 |
Hemlock Rivet, 6.4 mm |
| 10ar |
518326961 |
U-Attach |
| 10as |
293150266 |
Ornit Rivet 6,5 X 14.5 This part replaces 293150147. |
| 10at |
250000534 |
Tork Screw M6 X 16 |
| 10au |
233061414 |
Hex. Flange Nut M6 |
| 10d |
518325559 |
RH Engine Support |
| 10e |
293150096 |
Hemlock Rivet, 6.5 mm |
| 10f |
518326820 |
LH Stirup |
| 10g |
250000958 |
Panel Nut M5 X 0.8 |
| 10k |
293730052 |
Black, Plug |
| 10m |
293150203 |
Rivet Avibulb 3/16 |
| 10p |
518326960 |
Support |
| 10q |
250000536 |
Tork Screw M6 X 18 |
| 10r |
250200039 |
Flat Washer |
| 10t |
250300027 |
Clinch Stud M6 X 20 |
| 10u |
232561414 |
Elastic Stop Nut M6 |
| 10v |
250000535 |
Torx Screw M8 X 55 |
| 10y |
518324874 |
RH Reinforcement |
| 10z |
518324875 |
LH Reinforcement |
| 30 |
390402400 |
Pop Rivet 3/16" |
| 100 |
293150148 |
Rivet Magna-Grip 6,4 X 50,8 |
| 110 |
293150149 |
Collar Huck Magna-Grip 6.4 |
| 120 |
518325782 |
RH Deflector, Black Polypropylene |
| 130 |
518325783 |
LH Deflector, Black Polypropylene |
| 140 |
293150104 |
Pop Rivet 3/16" |
| 150 |
207561244 |
Hex. Flange Screw M6 X 12, Scotch Grip |
| 170 |
293150174 |
Hemlock Rivet, 6.4 mm |
| 1300b |
520000711 |
Full Moon RH Cap |
| 1300c |
520000712 |
Full Moon LH Cap |
| 1400 |
293730041 |
Full Moon Dart 8 mm |
