| Ref | Part Number | Description |
|---|
| 1 |
0202021 |
SPRING, Link to shallow water drive |
| 2 |
0381816 |
LEVER,Titl adj. |
| 3 |
0380871 |
STERN BRACKET ASSEMBLY PORT(INCL.ITEM 22) |
| 4 |
0326134 |
BOLT, Tilting This part replaces 0304277. |
| 5 |
0306344 |
BALL SLEEVE |
| 6 |
0132691 |
COMPRESSION NUT |
| 7 |
0310257 |
GASKET 5 INCH LONGER PARTS |
| 8 |
0312181 |
HOUSING,Exhaust |
| 9 |
0312926 |
WATER TUBE |
| 10 |
0317372 |
GROMMET, Wate tube, lower This part replaces 0203131. |
| 11 |
0308707 |
SCREW |
| 12 |
0312186 |
WASHER,Thrust |
| 13 |
0310270 |
LINING,Housing,upper |
| 15 |
0310271 |
LINING,Housing,lower |
| 17 |
0380103 |
SWIVEL BRACKET ASSEMBLY |
| 20 |
0310265 |
BLOCK,Friction |
| 21 |
0310266 |
SCREW,Friction block |
| 22 |
0391955 |
STERN BRACKET ASSY This part replaces 0380872. |
| 23 |
0433675 |
CLAMP SCR. & HAND. ASSY. This part replaces 0375742. |
| 26 |
0311281 |
HOOK,Reverse lock |
| 27 |
0311442 |
SPRING |
| 29 |
0306433 |
WASHER |
| 30 |
0302051 |
SPRING Tilting bolt |
| 31 |
0304278 |
WASHER |
| 32 |
0311279 |
SPRING, Long |
| 33 |
0301983 |
CONICAK WASHER,Stern brkt |
