| Ref | Part Number | Description |
|---|
| 1 |
420665791 |
ELECTRONIC CONTROL UNIT - Call your local BRP dealership |
| 2 |
420664550 |
ENGINE WIRING HARNESS - Call your local BRP dealership |
| 7 |
270600040 |
Pressure Sensor This part replaces 420274055. |
| 9 |
420966970 |
TEMPERATURE SENSOR - Call your local BRP dealership |
| 17 |
278001546 |
Ignition Coil |
| 18 |
420665335 |
Ignition Cable, Mag Side |
| 19 |
420660632 |
SLEEVE, MAG SIDE - Call your local BRP dealership |
| 20 |
278000237 |
SPARK PLUG CAP - Call your local BRP dealership |
| 21 |
420665333 |
Spark Plug Cable, 790 mm, Rear This part replaces 420665330. |
| 22 |
420660630 |
SLEEVE, PTO SIDE - Call your local BRP dealership |
