| Ref | Part Number | Description |
|---|
| 2 |
0580659 |
FLYWHEEL |
| 3 |
0580642 |
ARMATURE PLATE & POST |
| 4 |
0510191 |
SCREW |
| 6 |
0580971 |
COIL & LAMINATION |
| 8 |
0580148 |
BEAKER,Assy |
| 12 |
0510208 |
BOW WASHER |
| 13 |
0310350 |
SCREW, Armature plate |
| 14 |
0360252 |
WASHER This part replaces 0306311. |
| 15 |
0510188 |
CLIP, Oiler |
| 16 |
0510278 |
SCREW |
| 17 |
0510185 |
ECCENTRIC SCREW |
| 18 |
0580321 |
CONDENSER |
| 20 |
0510194 |
SCREW |
| 21 |
H.T.LEAD |
Ref: 22 0581027 *COVER & TERMINAL Assy, Spark plug 0581027 |
| 23 |
0312983 |
GROUND STRIP |
| 24 |
0312877 |
BARKT., Armature plate |
| 25 |
0120783 |
BAND, Identification |
| 26 |
0510409 |
CLAMP, H.T. lead |
| 27 |
0510397 |
SCREW |
| 28 |
0510391 |
BOW WAHSER,Eccentric scr. |
| 29 |
0314950 |
SLEEVE |
| 30 |
0329594 |
SCREW, Cam follower This part replaces 0303737. |
| 31 |
0315298 |
LINK, Arm plt. to throttle lever |
| 32 |
0380226 |
REATINER ASSEMBLY |
| 33 |
0315188 |
CAM, Armature plate |
| 35 |
0306413 |
WASHER |
| 36 |
0312759 |
COVER, Flywheel |
| 0580767 |
0580767 |
ARMATURE PLATE ASSEMBLY |
| 0580779 |
0580779 |
H. T. LEAD ASSY. |
