| Ref | Part Number | Description |
|---|
| 1 |
HOSE, |
Manifold cover plate, 5/8 inches I.D., 9 inches long |
| 2 |
HOSE, |
Water pump to exchanger, 1-3/4inch I.D. |
| 3 |
HOSE, |
Thermostat housing to expansion tank, -1/2 inches I.D., 24 inches long |
| 4 |
042-037 |
END CAP, Anode housing |
| 5 |
047-038 |
COVER, Thermostat housing |
| 6 |
079-032 |
GASKET, Thermostat housing |
| 7 |
079-033 |
GASKET, Thermostat housing cover |
| 8 |
072-018 |
THERMOSTAT, 160 deg |
| 9 |
HEAT |
EXCHANGER ASSY., Omc 313-4 |
| 10 |
415130437 |
Fuel Tank KIt |
| 10 |
SCREW, |
Upper mount, 3/8inch x 1-1/2inch |
| 11 |
SCREW, |
Lower mount, 3/8inch x 2-1/4inch |
| 12 |
LOCKWASHER, |
Screw, lower |
| 13 |
NUT, |
Screw, lower, 3/8inch |
| 14 |
CLAMP, |
Hose #10 |
| 15 |
CLAMP, |
Hose, #24 |
| 16 |
LEAD, |
Purple, 12inch with knife disconnects o n each end |
| 17 |
SLEEVES, |
Neoprene |
| 18 |
CLAMP, |
Large |
| 19 |
CLAMP, |
Small |
| 20 |
513033944 |
Fuel Tank Cap |
| 60 |
513033864 |
Fitting |
| 65 |
250000918 |
Truss Torx Screw K40 X 16 |
| 75 |
293650262 |
Oeticker Clamp |
| 80 |
219704410 |
Hose |
| 100 |
709200948 |
Grommet |
| 110 |
414580700 |
Male Connector |
| 300f |
732610072 |
Push Nut |
| 300k |
293300218 |
O Ring |
| 300m |
861805584 |
Fuel Filter This part replaces 513033992. |
| 300n |
293650207 |
Clamp Oetiker |
| 300p |
293650125 |
Oetiker Clamp |
| 300q |
293650053 |
Crimp Clamp |
| 310 |
513033798 |
Circlip |
| 320 |
513033862 |
O-Ring |
| 420 |
513034007 |
Socket |
| 430 |
503193995 |
Washer |
| 450 |
207663544 |
Hex. Flange Screw M6 X 35 |
| 500f |
513034047 |
Fuel Filter |
| 500g |
513034117 |
Y Fitting |
| 500j |
513033668 |
O-Ring |
| 500k |
293650125 |
Oetiker Clamp |
| 500m |
293650053 |
Crimp Clamp |
| 505 |
219704408 |
Sheath |
| 530 |
293650171 |
Tridon Gear Clamp |
| 540 |
250000760 |
Torx Screw Truss Head K50X20 T20 |
| 550 |
513034051 |
Hose Guide |
| 560b |
293650053 |
Crimp Clamp |
| 560d |
513033668 |
O-Ring |
| 600d |
513033668 |
O-Ring |
| 600f |
293650053 |
Crimp Clamp |
| 610 |
513033903 |
Bracket |
| 680 |
250000911 |
Hex. Flange Screw M5 X 16 |
| 690 |
250001018 |
Hex. Flanged Screw M5 X 28 S.Grip |
| 800 |
513033866 |
Insulated Foam |
