| Ref | Part Number | Description |
|---|
| 10 |
706004308 |
Deep Black, LH Upper Suspension Arm This part replaces 706001755. |
| 15 |
706004309 |
Deep Black, RH Upper Suspension Arm This part replaces 706001756. |
| 20 |
706003067 |
Deep Black, LH Lower Suspension Arm This part replaces 706001757. |
| 25 |
706003068 |
Deep Black, RH Lower Suspension Arm This part replaces 706001758. |
| 26 |
408200700 |
Grease Fitting |
| 35 |
706001898 |
Torsion Bar Link |
| 40 |
706004301 |
Stabilizer Bar Bushing This part replaces 706001896. |
| 42 |
408200700 |
Grease Fitting |
| 45 |
706002592 |
Clamp |
| 50 |
706005431 |
Stamped Washer This part replaces 706002027. |
| 55 |
706002028 |
Linkage Bushing |
| 60 |
715005488 |
Sway Bar Ass'y This part replaces 706002076. |
| 65 |
230600046 |
Hex Flange Screw DIN.6921 - Call your local BRP dealership |
| 70 |
706202197 |
Upper Bushing |
| 80 |
207607046 |
Hex. Flange Screw M10 X 70 |
| 85 |
706204409 |
Suspension Arm Bushing This part replaces 706201659. |
| 90 |
706201590 |
Sleeve |
| 95 |
207608046 |
Hex Flange Screw M10 X 80 |
| 100 |
706201660 |
Wear Plate |
| 130c |
706000910 |
Adjustment Ring |
| 130d |
706000911 |
Protector Ring |
| 130e |
706001894 |
Spring Cup |
| 140 |
703500875 |
Suspension Arm Bushing Kit This part replaces 706202088. |
| 150 |
703500875 |
Suspension Arm Bushing Kit |
| 170 |
207602544 |
Hex. Flange Screw M10 X 25 |
| 180 |
207606046 |
Hex. Flange Screw M10 X 6 |
| 190 |
233201436 |
Hex. Flange Elastic Nut M10 This part replaces 233201416. |
| 210 |
706002809 |
Rear Left Machined Knuckle This part replaces 706001793. |
| 220 |
706002811 |
Rear Right Machined Knuckle This part replaces 706001795. |
| 225 |
207607046 |
Hex. Flange Screw M10 X 70 |
