| Ref | Part Number | Description |
|---|
| 5000c |
705005055 |
Grommet Ass'y |
| 5000d |
250000958 |
Panel Nut M5 X 0.8 |
| 5000e |
207152060 |
Hex. Screw M5 X 20 |
| 5000f |
705003264 |
Grommet |
| 5000g |
250100198 |
Panel Nut M6 X 1.0 |
| 5010c |
705005055 |
Grommet Ass'y |
| 5010d |
250000958 |
Panel Nut M5 X 0.8 |
| 5010e |
207152060 |
Hex. Screw M5 X 20 |
| 5010f |
705003264 |
Grommet |
| 5010g |
250100198 |
Panel Nut M6 X 1.0 |
| 5020 |
250100198 |
Panel Nut M6 X 1.0 |
| 5030 |
250000722 |
Torx Screw M6 X 20 |
| 5040 |
250200029 |
Washer M6 |
| 5050 |
705007307 |
LH Side Grille |
| 5060 |
708000759 |
Rubber Stopper |
| 5070 |
705004803 |
RH Side Grille |
| 5080 |
293150230 |
Tuflok Plastic Rivet |
| 5090 |
705004789 |
LH Radiatior Moulding |
| 5100 |
705004790 |
RH Radiatior Moulding |
| 5160 |
207662544 |
Hex. Flange Screw M6 X 25 |
| 5170 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 5180 |
234062410 |
Flat Washer 6 mm |
| 5190 |
250100163 |
Pressure Nut |
| 5210 |
210261650 |
Hex. Flange Screw M6 X 16 |
| 5230 |
250000722 |
Torx Screw M6 X 20 |
| 5240 |
250100198 |
Panel Nut M6 X 1.0 |
| 5320 |
705006820 |
LH Lower Pannel |
| 5330 |
705007736 |
RH Lower Pannel |
| 5380 |
233281434 |
Hex. Flange Elastic Nut M8 |
| 5390 |
293150230 |
Tuflok Plastic Rivet |
| 5410 |
250100111 |
Panel Nut M8 |
| 5420 |
705007375 |
Panel Support |
| 5430 |
250100069 |
Panel Nut M8 X 1.25 |
| 5450c |
207652044 |
Hex.Flange Screw M5 X 20 |
| 5450d |
250000958 |
Panel Nut M5 X 0.8 |
| 5460c |
207652044 |
Hex.Flange Screw M5 X 20 |
| 5460d |
250000958 |
Panel Nut M5 X 0.8 |
| 5470 |
293150230 |
Tuflok Plastic Rivet |
| 5480 |
293150230 |
Tuflok Plastic Rivet |
| 5490 |
250000767 |
Torx Truss Screw M6 X 12 |
| 5590 |
705008999 |
Vegas White Pearl, LH Side Panel |
| 5590 |
705011189 |
Asphalt Gray LH Side Panel |
| 5590 |
705012003 |
Oxford Blue, LH Side Panel |
| 5590 |
705013512 |
Pheonix Orange, LH Side Panel |
| 5600 |
705008992 |
Bare, RH Side Panel This part replaces 705009000. |
| 5600 |
705011190 |
Asphalt Gray RH Side Panel |
| 5600 |
705012005 |
Oxford Blue, RH Side Panel |
| 5600 |
705013513 |
Pheonix Orange, RH Side Panel |
| 5650 |
293830143 |
Rubber Pad |
| 5660 |
250000759 |
Torx Truss Pt K40 X 16 |
| 5870 |
705004610 |
LH Deflector Pannel |
| 5880 |
705004611 |
RH Deflector Pannel |
| 5890 |
293150230 |
Tuflok Plastic Rivet |
| 5920 |
293150230 |
Tuflok Plastic Rivet |
| 5940 |
705005438 |
LH Skid Plate |
| 5950 |
705005439 |
RH Skid Plate |
| 7500b |
293750044 |
Tie Rap Mount |
| 7505b |
293750044 |
Tie Rap Mount |
| 7510 |
293150230 |
Tuflok Plastic Rivet |
| 7525 |
219704364 |
Neoprene Seal (1PAC=3M) |
| 7700 |
705004924 |
LH Lower Air Deflector |
| 7705 |
705004925 |
RH Lower Air Deflector |
| 7710 |
250000712 |
Torx Screw M6 X 20 |
| 7800 |
705006168 |
White LH Upper Panel |
| 7800 |
705010198 |
Asphalt Gray LH Upper Panel |
| 7800 |
705012007 |
Oxford Blue, LH Upper Panel |
| 7800 |
705013511 |
Poenix Orange, LH Upper Panel |
| 7801 |
518329812 |
Upper Panel Foam |
| 7802 |
518329821 |
LH Upper Panel Foam |
| 7805 |
705006212 |
Bare, RH Up Side Pan This part replaces 705006167. |
| 7805 |
705010199 |
Asphalt Gray RH Upper Panel |
| 7805 |
705012009 |
Oxford Blue, RH Upper Panel |
| 7805 |
705013510 |
RH UPPER PANEL B-424 - Call your local BRP dealership |
| 7806 |
518329820 |
RH Upper Panel Foam |
| 7810 |
250000722 |
Torx Screw M6 X 20 |
| 7815 |
234062670 |
Stainless Steel Flat Washer |
| 7840 |
705003842 |
Knob |
| 7845 |
705003746 |
Angled Knob |
| 7850 |
250000459 |
Torx Screw, K50X16 |
| 7855 |
219704368 |
Seal Tray 1000Mm Long |
| 8150 |
705003385 |
LH Upper Side Panel Grille |
| 8155 |
705003386 |
RH Upper Side Panel Grille |
| 8160 |
517302785 |
Edge Clip |
| 8250 |
705006178 |
White LH Lateral Panel |
| 8250 |
705011191 |
Asphalt Gray LH Lateral Panel |
| 8250 |
705012011 |
Oxford Blue, LH Upper Lateral Panel |
| 8250 |
705013514 |
Pheonix Orange, LH Upper Lateral Panel |
| 8255 |
705006177 |
White RH Upper Lateral Panel |
| 8255 |
705011192 |
Asphalt Gray RH Lateral Panel |
| 8255 |
705012013 |
Oxford Blue, RH Panel |
| 8255 |
705013515 |
Pheonix Orange, RH Upper Lateral Panel |
| 8260 |
705000321 |
Oval Washer |
| 8265 |
250000722 |
Torx Screw M6 X 20 |
| 8270 |
234062670 |
Stainless Steel Flat Washer |
| 8275 |
250100198 |
Panel Nut M6 X 1.0 |
