| Ref | Part Number | Description |
|---|
| B |
293800060 |
LOCTITE 243 GREEN |
| C |
219703000 |
Sealant Loctite 648 This part replaces 413711400. |
| O |
293600112 |
ENGINE OIL |
| 1 |
420911052 |
IGNITION COVER |
| 7 |
420685635 |
STATOR ASSY. 14V 650W |
| 9 |
420686190 |
MAG. FLYWHEEL WITH TRIGGER WHEEL ASSY |
| 10 |
420627270 |
Shim A17 DIN 125 |
| 13 |
420659113 |
Sprag Clutch 51,710x68,377x13 |
| 14 |
420659263 |
Sparg Clutch Housing This part replaces 420659261. |
| 15 |
420434238 |
Free Wheel Gear 64 T Ass'y This part replaces 420434237. |
| 16 |
420229475 |
Needle Pin ISO 8734-10X65-B-ST |
| 17 |
420634741 |
STARTER DOUBLE GEAR 11/49 T. |
| 21 |
420866714 |
Tie Rap 142x3,2 MM |
| 22 |
420881141 |
Carbon Brush Set This part replaces 420881140. |
