| Ref | Part Number | Description |
|---|
| 2 |
420632010 |
Center Pin 8 X 12 |
| 3 |
420656973 |
Oil Spraying Jet This part replaces 420656972. |
| 4 |
420840658 |
Plug Screw M12x1,5 |
| 5 |
420641317 |
Plug Screw M20 X 1.5 |
| 6 |
420441050 |
Plug Screw M18 X 1.5 |
| 7 |
420641323 |
Plug Screw M10 X 1 |
| 8 |
420933858 |
Plain Bearing |
| 9 |
420233848 |
Plain Bearing |
| 10 |
420233846 |
Plain Bearing |
| 11 |
420929075 |
Needle Pin |
| 12 |
420230150 |
Oil Seal |
| 12 |
XXX |
Not Available As Spare Parts |
| 13 |
XXX |
Not Available As Spare Parts |
| 14 |
XXX |
Not Available As Spare Parts |
| 15 |
XXX |
Not Available As Spare Parts |
| 16 |
Not |
Available As Spare Part - Oil Pump Cover |
| 17 |
420230150 |
Oil Seal |
| 18 |
420441630 |
Bleeder Screw M10 X 1 |
| 19 |
420933475 |
Half-Ring |
| 20 |
420940945 |
Torx Flange Screw M9 X 113 |
| 21 |
420441085 |
Torx Flange Screw M8 x 70 |
| 22 |
420440485 |
Torx Flange Screw M8 x 40 |
| 23 |
420440274 |
Torx Flange Screw M6 X 35 |
| 24 |
420250610 |
Gasket |
| 25 |
420611740 |
Oil Sump |
| 26 |
420941614 |
Plug Screw M8 x 1 |
| 27 |
420440234 |
Torx Flange Screw M6 X 25 |
| 29 |
420641733 |
Plug Screw M10 X 1 |
| 30 |
420664031 |
Noise Sensor |
| 31 |
420641188 |
Torx Flange Screw M8 X 35 This part replaces 420440867. |
| 32 |
420440274 |
Torx Flange Screw M6 X 35 |
| 33 |
XXX |
Not Available As Spare Parts |
| 34 |
Not |
Available As Spare Part - Intermediate Gear Shaft |
| 35 |
Not |
Available As Spare Part - Bearing Bracket |
| 36 |
Not |
Available As Spare Part - Flange Torx Screw M8 X 65 |
| 37 |
Not |
Available As Spare Part - Oil Pump Cover |
