| Ref | Part Number | Description |
|---|
| 1 |
0982336 |
CAP ASSY, Dist This part replaces 0980900. |
| 2 |
0980892 |
ROTOR |
| 3 |
0980895 |
PLATE ASSY |
| 4 |
0980893 |
CON SET, Brkr |
| 5 |
0980894 |
CONDENSER |
| 6 |
0982018 |
DISTRIBUTOR SHAFT & HOUSING ASSY |
| 7 |
0981057 |
BEARING & PARTS PACKAGE |
| 8 |
0980899 |
CAP SPRING PACKAGE |
| 9 |
0980896 |
LEAD ASSEMBLY |
| 10 |
3853793 |
O-RING This part replaces 0981702. |
| 10b |
519000373 |
Oil Tank Cap Ass'y |
| 11 |
3853790 |
GEAR, COLLAR & PARTS PKG. This part replaces 0981058. |
| 12 |
0306450 |
SCREW |
| 14 |
0981781 |
LEAD ASSY, Spark plug #5 & 1 |
| 14 |
0981782 |
LEAD ASSY, Cylinders 5 & 6 |
| 14 |
0981783 |
LEAD ASSY, Cylinder 3 & 4 |
| 14 |
0981785 |
LEAD ASSY, Cylinder 1 & 2 |
| 15 |
0580558 |
LEAD ASSEMBLY, Coil |
| 16 |
D0OZ-12043-A |
STRAP, Ign, coil |
| 17 |
57018-S |
BOLT, Strap to coil |
| 18 |
34052-S |
NUT, Strap to coil |
| 20 |
0550757 |
L'WASHER,Coil term |
| 70 |
861805524 |
Support |
| 80 |
243141630 |
Hex. Plastic Screw M4.8 X 16 |
| 90 |
207561044 |
Flange Screw M6 X 10, Scotch Grip |
| 100 |
205561644 |
Socket Screw M6 X 16, Scotch Grip |
| 110 |
224061201 |
Flat Washer |
| 150 |
519000320 |
Clamp |
| 160 |
250000760 |
Torx Screw Truss Head K50X20 T20 |
| 200 |
519000322 |
Hose Protector |
| 210 |
293150104 |
Pop Rivet 3/16 |
| 300 |
414420700 |
Universal Spring Clamp |
| 350 |
293650252 |
Hose Clamp |
| 400a |
415130335 |
O-Ring |
| 410 |
519000318 |
Bracket |
| 420 |
250000760 |
Torx Screw Truss Head K50X20 T20 |
| 430 |
293650099 |
Oetiker Gear Clamp |
| 500 |
250000741 |
Screw-Torx Button Head M4 X 8 |
| 510 |
234141601 |
Lock Washer 4 mm |
| 0981080 |
0985764 |
DISTRIBUTOR ASSY. This part replaces 0981080. |
