| Ref | Part Number | Description |
|---|
| 300b |
518327487 |
Front Suspension Support This part replaces 518327475. |
| 300c |
207662044 |
Hex. Flange Screw M6 X 20 |
| 300d |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 300e |
293150144 |
Stavex Rivet |
| 300f |
518327565 |
Front Member |
| 300g |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 300h |
207662044 |
Hex. Flange Screw M6 X 20 |
| 300i |
207662044 |
Hex. Flange Screw M6 X 20 |
| 300j |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 310 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 320 |
210261650 |
Hex. Flange Screw M6 X 16 This part replaces 210261680. |
| 330 |
207662544 |
Hex. Flange Screw M6 X 25 |
| 340 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 350 |
293150191 |
Monobolt Rivet, 4.8 mm |
| 360 |
293150182 |
Monobolt Rivet 6.4 |
| 370 |
207661644 |
Hex. Flange Screw M6 X 16 |
| 380 |
518326466 |
MODULE REINFORCEMENT - Call your local BRP dealership |
| 390 |
293150266 |
Ornit Rivet 6,5 X 14.5 This part replaces 293150147. |
| 420 |
293730053 |
Black Dart 5 mm |
| 500 |
518328346 |
Pulley Support This part replaces 518326651. |
| 510 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 530 |
518326118 |
LINK - Call your local BRP dealership |
| 540 |
207563034 |
Hex. Flange Screw M6 X 30, Scotch Grip This part replaces 207663044. |
| 550 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 560 |
250000143 |
Torx Screw M8 X 25, Scotch Grip |
| 900 |
518326559 |
Rear Member |
| 910 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 1100 |
518325114 |
Upper Lateral Column Support |
| 1110 |
207662044 |
Hex. Flange Screw M6 X 20 |
| 1120 |
233261416 |
Elastic Flange Nut M6 X 1.0 |
| 1200 |
518325115 |
Center Column Support |
| 1210 |
207662544 |
Hex. Flange Screw M6 X 25 |
| 1220 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 1300 |
518325481 |
Black Rear Bumper 137" |
| 1310 |
250000779 |
Torx Screw M6 X 1.0 X 18, Scotch Grip This part replaces 250000402. |
| 1400 |
293730047 |
Black, Dart 8 mm |
| 1700 |
518326973 |
Front Tunnel Protector |
| 1720 |
207152044 |
Hex. Screw M5 X 20 |
| 1730 |
391301600 |
Washer |
| 1740 |
233251434 |
Flange Elastic Nut M5 This part replaces 233251414. |
| 1800 |
518328106 |
RH FOOTREST - Call your local BRP dealership This part replaces 518327129. |
| 1810 |
518328107 |
LH FOOTREST - Call your local BRP dealership This part replaces 518327130. |
| 1820 |
250000767 |
Torx Truss Screw M6 X 12 This part replaces 250000325. |
| 1830 |
250000365 |
Torx Screw M6 X 16 |
| 2000 |
518327131 |
LH BRACKET - Call your local BRP dealership |
| 2100 |
518327132 |
RH BRACKET - Call your local BRP dealership |
