| Ref | Part Number | Description |
|---|
| 2 |
0397018 |
YOKE & THUMBWHEEL |
| 9 |
0908398 |
WASHER |
| 10 |
0432015 |
LEVER Assy, Spark |
| 15 |
0398134 |
THROTTLE CAM |
| 16 |
0338676 |
BUMPER, Idle stop |
| 20 |
0308776 |
O-RING |
| 21 |
0334238 |
VIS, levier vers cylindre |
| 22 |
0318660 |
BUMPER, Screw, throttle stop |
| 23 |
0908398 |
WASHER |
| 24 |
0432572 |
ROLLER & SLEEVE ASSY |
| 26 |
0206409 |
PIVOT SCREW |
| 27 |
0332143 |
ROD, Lever to cam |
| 28 |
0127386 |
RONDELLE This part replaces 0303913. |
| 29 |
0328699 |
LEVER, Spark control |
| 31 |
0319545 |
VIS, supports de montage supérieurs vers support de direction |
| 33 |
0303398 |
VIS, support |
| 34 |
0328737 |
RONDELLE, levier de sens de marche et manette des gaz |
| 36 |
0339220 |
SCREW, Spark control cam |
| 42 |
0432684 |
SHELL |
