| Ref | Part Number | Description |
|---|
| 1 |
515175664 |
Heating Grip |
| 2 |
293750001 |
Tie Wrap 94 mm |
| 3 |
515175314 |
GAINE LOW TEMP.VINYL - Call your local BRP dealership |
| 4 |
219704424 |
Vinyl Tubing, Low Temp 3000Mm Long |
| 5 |
409207200 |
Female Lock |
| 6 |
515177434 |
DIMMER SWITCH - Call your local BRP dealership This part replaces 515175684. |
| 7 |
409207500 |
Male Lock, 2 Circuits |
| 8 |
Not |
Available As Spare Part - Microswitch Ass'y |
| 9 |
515177454 |
KILL SWITCH - Call your local BRP dealership This part replaces 515175685. |
| 10 |
512060214 |
Handle Ass'y This part replaces 512059152. |
| 11 |
414115200 |
Tie-Rap 180 mm |
| 12 |
515175666 |
Male Housing |
| 13 |
278002375 |
CONNECTOR_FEMALE 3 CAVITIES - Call your local BRP dealership This part replaces 409207400. |
| 14 |
278000631 |
Male Terminal |
| 15 |
515175669 |
MALE HOUSING - Call your local BRP dealership |
| 16 |
515175704 |
FEMALE TERMINAL HOUSING, 12 CIRCUITS - Call your local BRP dealership |
| 17 |
278000632 |
Female Terminal |
| 18 |
278001276 |
FEMALE TERMINAL - Call your local BRP dealership |
| 19 |
409207500 |
Male Lock, 2 Circuits |
| 20 |
515175679 |
FEMALE LOCK, 12 CIRCUITS - Call your local BRP dealership |
| 21 |
293000052 |
Sealing Cap |
| 22 |
409015600 |
MALE LOCK, 12 CIRCUITS - Call your local BRP dealership |
| 23 |
278000739 |
Male Connector, 4 Circuits |
| 24 |
278000738 |
Male Lock, 4 Circuits |
| 25 |
515175765 |
Switch Harness Ass'y |
