| Ref | Part Number | Description |
|---|
| 4 |
0512743 |
DISPOSITIF DE RETENUE |
| 7 |
0175905 |
CABLE ASSY., 18 ft. (5,5m) |
| 15 |
5007356 |
Kit Ay This part replaces 0434326. |
| 16 |
0511807 |
COVER&GASKET AY |
| 17 |
0333448 |
GASKET |
| 29 |
0329182 |
VIS, borne |
| 47 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 48 |
HOSE, |
Primer to carb, 3 1/2 in. (82mm) |
| 49 |
HOSE, |
Tee to primer, 1 in. (25mm) |
| 51 |
0175925 |
CABLE, Engine |
| 59 |
0514051 |
FUSE, 20 Amp |
| 63 |
3853565 |
CONNECTOR This part replaces 0915842. |
| 67 |
3853564 |
CONNECTOR This part replaces 0915841. |
| 70 |
0512741 |
DISPOSITIF DE RETENUE, conn. de l'interrupteur thermostatique |
| 71 |
0512742 |
DISPOSITIF DE RETENUE, connecteur |
| 72 |
0512743 |
DISPOSITIF DE RETENUE |
| 76 |
0337976 |
SCREW, Shift lever |
| 77 |
0338250 |
ENTRETOISE, manette des gaz |
| 0175904 |
0176905 |
KIT ASSY., Remote start This part replaces 0175904. |
