| Ref | Part Number | Description |
|---|
| 1 |
0433926 |
BOW ARM ASSY. This part replaces 0386543. |
| 2 |
0321351 |
PIVOT PIN, Latch |
| 3 |
0333726 |
SPRING This part replaces 0319745. |
| 4 |
0116529 |
LATCH, Bow arm This part replaces 0319742. |
| 5 |
0320356 |
EYELET |
| 6 |
0397886 |
BRACKET & PIN ASSY. This part replaces 0319461. |
| 7 |
0386487 |
KNOB, Adjustment |
| 8 |
0328395 |
PIN, Arm to bracket This part replaces 0319651. |
| 9 |
0432081 |
MOUNTING BRACKET ASSY., Arm to deck This part replaces 0387498. |
| 10 |
0319750 |
PAD, Deck bracket |
| 11 |
0320791 |
PAD |
| 12 |
0116414 |
SCREW, Plate to bracket This part replaces 0321333. |
| 13 |
0321334 |
PLATE, Bow arm latch |
| 17 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 18 |
0319851 |
SCR3EW, Mounting brkt to boat |
| 19 |
0319652 |
SET SCREW, Adj. ring |
| 20 |
0309335 |
WASHER |
| 21 |
0319711 |
DRUM, Cable |
| 22 |
0334291 |
PIN, Arm to deck bracket This part replaces 0319649. |
| 24 |
0324513 |
HANDLE |
| 25 |
0397704 |
CABLE ASSY., Bow arm This part replaces 0386538. |
