| Ref | Part Number | Description |
|---|
| 2 |
0210305 |
APPLIQUE |
| 4 |
0328686 |
SEAL, Engine cover |
| 5 |
0389971 |
LOCATING BARCKET, Front |
| 6 |
0394976 |
LOCATING BRACKET, Rear |
| 8 |
0210499 |
APPLIQUE, Front |
| 9 |
0321256 |
SOUND BLANKET, Top |
| 11 |
0323175 |
HOOK , Motor Cover, Front |
| 12 |
0210499 |
APPLIQUE, Front |
| 13 |
0335036 |
APPLIQUE, Front |
| 21 |
0211263 |
PLATE, Applique, front |
| 21 |
0211426 |
PLATE, Applique, front |
| 22 |
0211262 |
LOUVER, Port |
| 22 |
0335045 |
LOUVER, Engine cover, port |
| 23 |
0211261 |
LOUVER, Starboard |
| 23 |
0335046 |
LOUVER, Engine cover, stbd |
| 24 |
0329737 |
BAFFLE, 175STL |
| 25 |
0329866 |
BRACKET, Louver mtg |
| 31 |
0328695 |
CLAMP, Engine cable |
| 32 |
0303398 |
VIS, support |
| 34 |
0328695 |
CLAMP, Engine cable |
| 35 |
0316354 |
ENGINE COVER SUPPORT GROMMET |
| 36 |
0302406 |
SLEEVE |
| 37 |
0303398 |
VIS, support |
| 38 |
0333739 |
RETAINER, Fuel hose to cover |
| 40 |
0392494 |
FRAME AND SEAL ASSY |
| 41 |
0318258 |
SEAL Cover |
| 42 |
0328358 |
COVER ASSY. Air entrance |
| 43 |
0315111 |
SUPPORT, Front |
| 44 |
0315113 |
SUPORT, Stbd, rear |
| 45 |
0315112 |
SUPPORT, Port rear |
| 46 |
0328695 |
CLAMP, Engine cable |
| 48 |
0318849 |
CLAMP, Instrument cable |
| 49 |
0434288 |
ENGINE COVER, Lower This part replaces 0432658. |
| 51 |
0320834 |
GROMMET |
| 52 |
0323170 |
HOOK Front and stbd., rear |
| 54 |
0395757 |
LATCH HANDLE ASSY., Front |
| 56 |
0323169 |
HOOK, Lower rear port |
| 57 |
0395758 |
LATCH HANDLE ASSY., Rear |
| 58 |
0908159 |
SCREW, Bearing clamp This part replaces 0328728. |
| 59 |
0321885 |
NIPPLE |
| 60 |
0394309 |
FUEL CONNECTOR |
| 63 |
0328695 |
CLAMP, Engine cable |
| 65 |
0331533 |
JOINT, conn. carburant vers capot inférieur |
| 0211138 |
0211138 |
OWNER'S MANUAL, 175STL |
| 0283668 |
0283668 |
ENGINE COVER ASSY. |
| 0283768 |
0283957 |
ENGINE COVER ASSY., This part replaces 0283768. |
| 0283780 |
0283780 |
DECAL SET |
