| Ref | Part Number | Description |
|---|
| ACC |
515175231 |
Female Terminal |
| ACC |
515175658 |
Female Housing, 2 Circuits |
| ATS |
515176890 |
Female Terminal Housing |
| ATS |
710001163 |
Wire Seal |
| ATS |
710001164 |
Female Terminal |
| COM |
278000632 |
Female Terminal |
| COM |
278001665 |
Female Terminal |
| COM |
278002896 |
Housing, 6 Circuits |
| COM |
293000052 |
Sealing Cap |
| COM |
515175678 |
Male Wedge, 6 Circuits |
| CPS |
278000631 |
Male Terminal |
| CPS |
409207500 |
Male Lock, 2 Circuits |
| CPS |
515175665 |
Male Terminal Housing, 2 Circuits |
| CTS |
278000631 |
Male Terminal |
| CTS |
409206900 |
Male Housing, 2 Circuits |
| CTS |
409207500 |
Male Lock, 2 Circuits |
| ECM |
515175806 |
Female Terminal |
| ECM |
515175812 |
Plug |
| ECM |
515176221 |
Female Housing |
| ECM |
515176222 |
Wire Seal |
| ECM |
515176223 |
Female Terminal Housing, 36 Circuits |
| ECM |
515176224 |
Terminal Support |
| ECM |
710001131 |
Female Terminal |
| EGTS |
710001224 |
Terminal |
| EGTS |
710001233 |
Seal |
| F1 |
278000805 |
Cushion |
| F1 |
278001325 |
Fuse Holder |
| F1 |
278001326 |
Fuse Holder Cap |
| F1 |
409003900 |
Fuse, 20 Amperes |
| F1 |
710000113 |
Female Terminal |
| FLS |
515175232 |
Male Terminal |
| FLS |
515175654 |
Male Terminal Housing, 2 Circuits |
| GND |
278000992 |
Open Barrel |
| HL |
515177296 |
Female Housing |
| HL |
710001228 |
Terminal |
| HL |
710001332 |
Seal Wire |
| IGN |
409010100 |
Female Terminal |
| IGN |
409010400 |
Female Terminal Housing, 1 Circuit |
| KILL |
278000632 |
Female Terminal |
| KILL |
515175670 |
Female Terminal Housing, 2 Circuits |
| KILL |
515175675 |
Female Lock, 2 Circuits |
| MG |
515175801 |
Female Housing, 24 Circuits |
| MG |
515175802 |
Retainer Block |
| MG |
515175803 |
Wire Seal |
| MG |
515175806 |
Female Terminal |
| MG |
515175812 |
Plug |
| MG |
710000399 |
Female Housing |
| MG |
710001131 |
Female Terminal |
| PW1 |
278001672 |
Male Lock, 2 Circuits |
| PW1 |
278001674 |
Mâle Terminal Housing, 2 Circuits |
| PW1 |
515175568 |
Male Terminal |
| PW2 |
278001671 |
Female Lock, 2 Circuits |
| PW2 |
278001673 |
Female Terminal Housing, 2 Circuits |
| PW2 |
515175567 |
Female Terminal |
| R1 |
409209900 |
Female Housing, 5 Circuits |
| R1 |
561503100 |
FEMALE TERMINAL - Call your local BRP dealership |
| R1 |
710010053 |
Relay This part replaces 515177041. |
| REG |
515176530 |
Connector |
| REG |
515176531 |
Terminal |
| REG |
515176594 |
Seal |
| RES |
710002674 |
Resistor |
| SH1 |
710001223 |
Terminal |
| SH1 |
710001224 |
Terminal |
| SH1 |
710001225 |
Cap |
| SH1 |
710001233 |
Seal |
| SH1 |
710001332 |
Seal Wire |
| SH1 |
710001929 |
Housing, Packard |
| SH2 |
710001224 |
Terminal |
| SH2 |
710001225 |
Cap |
| SH2 |
710001233 |
Seal |
| SH2 |
710001927 |
Housing |
| TETHER |
278000632 |
Female Terminal |
| TETHER |
515175670 |
Female Terminal Housing, 2 Circuits |
| TETHER |
515175675 |
Female Lock, 2 Circuits |
| TL |
515178013 |
Male Terminal |
| TL |
515178023 |
Housing |
| TPS |
515176176 |
Female Terminal Housing, 3 Circuits |
| TPS |
710000335 |
Female Terminal |
| TPS |
710000402 |
Wire Seal |
| VSS |
515176621 |
Wire Seal |
| VSS |
710000568 |
Housing |
| VSS |
710000992 |
Clip |
| 1 |
515177994 |
WIRING HARNESS ASSY - Call your local BRP dealership |
