| Ref | Part Number | Description |
|---|
| BM |
278000992 |
Open Barrel |
| BP |
278000992 |
Open Barrel |
| CM |
278002307 |
FEMALE TERMINAL - Call your local BRP dealership |
| CM |
293750002 |
Tie Wrap 142 mm |
| CM |
409209600 |
Female Housing, 3 Circuits |
| CM |
515176621 |
Wire Seal |
| COM |
278000632 |
Female Terminal |
| COM |
293000052 |
Sealing Cap |
| COM |
515175673 |
Male Housing, 6 Circuits |
| COM |
515175678 |
Male Wedge, 6 Circuits |
| CV |
515175801 |
Female Housing, 24 Circuits |
| CV |
515175802 |
Retainer Block |
| CV |
515175803 |
Wire Seal |
| CV |
515175806 |
Female Terminal |
| CV |
515175812 |
Plug |
| CV |
710000399 |
Female Housing |
| CV |
710001131 |
Female Terminal |
| DS |
515175231 |
Female Terminal |
| DS |
515175495 |
Female Housing, 3 Circuits |
| ECMB |
278001750 |
FEMALE TERMINAL - Call your local BRP dealership |
| ECMB |
278001751 |
MALE HOUSING, 41 CIRCUITS - Call your local BRP dealership |
| ECMB |
420664450 |
ECM Connector |
| ECMB |
515175883 |
Latch |
| ECMB |
515175884 |
LOCK - Call your local BRP dealership |
| ECMB |
515175885 |
COVER - Call your local BRP dealership |
| ECMB |
515175886 |
SEAL - Call your local BRP dealership |
| F |
710000742 |
Little Fuse, 5 Amperes |
| F |
710000743 |
Little Fuse, 7.5 Amperes |
| F |
710000744 |
Little Fuse, 10 Amperes |
| F |
710000745 |
Little Fuse, 15 Ampere |
| F |
710000746 |
Little Fuse, 20 Amperes |
| F |
710000747 |
Little Fuse, 30 Amperes |
| FAN |
515176164 |
Male Terminal |
| FAN |
515176621 |
Wire Seal |
| FAN |
710000568 |
Housing |
| HG |
515175231 |
Female Terminal |
| HG |
515175282 |
Female Terminal |
| HG |
515175349 |
FEMALE TERMINAL HOUSING, 13 CIRCUITS - Call your local BRP dealership |
| HIC |
278000738 |
Male Lock, 4 Circuits |
| HIC |
278000739 |
Male Connector, 4 Circuits |
| HIC |
278001665 |
Female Terminal |
| HIC |
293000052 |
Sealing Cap |
| HO |
515175231 |
Female Terminal |
| HO |
515175658 |
Female Housing, 2 Circuits |
| NE |
515175232 |
Male Terminal |
| NE |
515175654 |
Male Terminal Housing, 2 Circuits |
| NV |
515176164 |
Male Terminal |
| NV |
515176621 |
Wire Seal |
| NV |
710000568 |
Housing |
| NV |
710000992 |
Clip |
| PA |
515176908 |
Female Housing |
| PA |
515176909 |
Terminal |
| PB |
515176908 |
Female Housing |
| PB |
515176909 |
Terminal |
| PE |
278001013 |
Wire Seal |
| PE |
278001014 |
Female Terminal |
| PE |
409209500 |
Female Housing, 2 Circuits |
| PF |
278002172 |
Foam |
| PF |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| PF |
710000781 |
Fuse Puller |
| PF |
710001026 |
Fuse Cover |
| R |
515176774 |
Relay, 30 AMP |
| R |
515176775 |
Relay, 50 AMP |
| RE |
710000877 |
Female Terminal |
| RE |
710000879 |
Female Housing, 3 Circuits |
| RE |
710000881 |
Seal |
| RE |
710000882 |
Cap |
| RPO |
515175232 |
Male Terminal |
| RPO |
515175494 |
Male Housing, 3 Circuits |
| RS |
278002307 |
FEMALE TERMINAL - Call your local BRP dealership |
| RS |
409209600 |
Female Housing, 3 Circuits |
| RS |
515176621 |
Wire Seal |
| SA |
515175231 |
Female Terminal |
| SA |
515175495 |
Female Housing, 3 Circuits |
| SB |
515176164 |
Male Terminal |
| SB |
515176621 |
Wire Seal |
| SB |
710000568 |
Housing |
| SD |
293750001 |
Tie Wrap 94 mm |
| SD |
409010100 |
Female Terminal |
| SD |
409010400 |
Female Terminal Housing, 1 Circuit |
| SW1 |
409010100 |
Female Terminal |
| SW1 |
409010400 |
Female Terminal Housing, 1 Circuit |
| VC1 |
409010100 |
Female Terminal |
| 910 |
278002307 |
FEMALE TERMINAL - Call your local BRP dealership |
| 910 |
293750002 |
Tie Wrap 142 mm |
| 910 |
409209600 |
Female Housing, 3 Circuits |
| 910 |
515176621 |
Wire Seal |
