15-6_CYLINDER & CRANKCASE ASSEMBLY
Parts (18)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5041403 | CYLINDER & CRANKCASE ASSEMBLY |
| 6 | 5041054 | THERMOSTAT CAP |
| 7 | 5040066 | THERMOSTAT CAP GASKET |
| 8 | 5041564 | BOLT |
| 9 | 5041404 | EXHAUST COVER (OUTER) |
| 10 | 5041277 | EXHAUST COVER GASKET |
| 11 | 5040146 | ANODE |
| 13 | 5041088 | ANODE PLUG |
| 14 | 5041186 | GASKET |
| 16 | 5041441 | PLUNGER ASSEMBLY |
| 17 | 5041311 | OIL STRAINER ASSEMBLY |
| 18 | 5041732 | Hose This part replaces 5041726. |
| 19 | 5040220 | BAND LEAD WIRE 158 |
| 20 | 5041272 | ENGINE BASEMENT GASKET |
| 21 | 5041669 | WASHER |
| 22 | 5041207 | BOLT 8-35 |
| 23 | 5041730 | Hose This part replaces 5041719. |
| 24 | 5041561 | BOLT |
