| Ref | Part Number | Description |
|---|
| 1 |
0388779 |
MOTORCOVERASSY.,175hp |
| 1 |
0388780 |
MOTORCOVERASSY.,235hp |
| 1 |
0389391 |
MOTORCOVERASSY.,200hp |
| 1 |
0389845 |
MOTORCOVERASSY.,150hp |
| 2 |
0394976 |
LOCATING BRACKET, Rear This part replaces 0206322. |
| 3 |
0323175 |
HOOK , Motor Cover, Front |
| 4 |
0325172 |
SOUND BLANKET, Side This part replaces 0321257. |
| 7 |
0306407 |
LOCCKWASHER,Cover latch |
| 10 |
0314494 |
BAG EMERGENCY STARTER ROPE |
| 11 |
0321256 |
SOUND BLANKET, Top |
| 12 |
0389971 |
LOCATING BARCKET, Front This part replaces 0207513. |
| 14 |
0328686 |
SEAL, Engine cover This part replaces 0321255. |
| 15 |
SEAL,Baffletohandle |
Ref: 16 0315159 **BUMPER, Locating brackets 0315159 |
| 17 |
0206520 |
AIR INLET BAFFLE |
| 19 |
0388783 |
APPLIQUE,Front |
| 21 |
0325857 |
SCREW, Fuel connector This part replaces 0304151. |
| 22 |
0393334 |
CONNECTEUR, carburant - mâle This part replaces 0376154. |
| 23 |
0552062 |
SCREW, Clamp |
| 24 |
0302406 |
SLEEVE |
| 25 |
0383685 |
LATCH HANDEL ASSY., Rear |
| 27 |
0306493 |
SCREW, Regulator mounting |
| 28 |
0328695 |
CLAMP, Engine cable This part replaces 0323480. |
| 29 |
0378347 |
CORDE DE LANCEUR |
| 30 |
0315111 |
SUPPORT, Front |
| 31 |
0383641 |
LATCH HANDEL ASSY., Front |
| 32 |
0316354 |
ENGINE COVER SUPPORT GROMMET |
| 33 |
0311375 |
NUT |
| 34 |
0315113 |
SUPORT, Stbd, rear |
| 35 |
0315112 |
SUPPORT, Port rear |
| 36 |
0307151 |
SCREW |
| 37 |
0318849 |
CLAMP, Instrument cable |
| 38 |
0333739 |
RETAINER, Fuel hose to cover This part replaces 0318313. |
| 39 |
0328695 |
CLAMP, Engine cable This part replaces 0323480. |
| 40 |
0302288 |
BOLT |
| 41 |
0392494 |
FRAME AND SEAL ASSY This part replaces 0387443. |
| 42 |
0318258 |
SEAL Cover |
| 43 |
0328358 |
COVER ASSY. Air entrance This part replaces 0323154. |
| 44 |
0303398 |
VIS, support This part replaces 0302030. |
| 46 |
0328695 |
CLAMP, Engine cable This part replaces 0323480. |
| 47 |
0328695 |
CLAMP, Engine cable This part replaces 0323480. |
| 49 |
0434288 |
ENGINE COVER, Lower This part replaces 0388943. |
| 50 |
0320834 |
GROMMET |
| 53 |
0323170 |
HOOK Front and stbd., rear |
| 54 |
0321885 |
NIPPLE |
| 55 |
0310539 |
SCREW, Clamp choke solenoid |
| 56 |
0323169 |
HOOK, Lower rear port |
| 0388790 |
0388790 |
DECALSET,175hponly |
| 0388791 |
0388791 |
DECALSET,135hponly |
| 0389392 |
0389392 |
DECALSET,200hponly |
| 0389846 |
0389846 |
DECALSET,150hponly |
