| Ref | Part Number | Description |
|---|
| 1 |
351004190 |
Engine |
| 2 |
605250905 |
ENGINE MOUNT. PLATE - Call your local BRP dealership |
| 3 |
512059425 |
FRONT ENGINE SUPPORT - Call your local BRP dealership |
| 4 |
20005 |
WASHER M10 - Call your local BRP dealership |
| 5 |
20113 |
Spring washer M10 |
| 6 |
205003544 |
Screw M10 x 35 |
| 7 |
40352 |
Socket head screw M10 x 40 |
| 8 |
512059691 |
Rubber mount |
| 9 |
40041 |
Screw M10 x 30 |
| 10 |
605350835 |
ENGINE REAR SUPPORT - Call your local BRP dealership |
| 11 |
512056700 |
Lock washer |
| 12 |
40335 |
Screw M10 x 30 |
| 13 |
512059316 |
Rubber mount |
| 14 |
33074 |
NUT-FLANGE ELASTIC M10X1.5 (1=10pcs) - Call your local BRP dealership |
| 15 |
512059710 |
STOPPER - Call your local BRP dealership |
| 16 |
605250844 |
MODULE SUPPORT - Call your local BRP dealership |
| 17 |
36083 |
Rivet |
| 18 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 This part replaces 33200. |
| 19 |
12419 |
Rubber mount |
| 20 |
40327 |
Screw M6 x 16 |
| 21 |
40053 |
Socket head screw M10 x 25 |
| 22 |
293800060 |
Liima Loctite 243, 10ml |
| 23 |
210251650 |
Screw-Forming Hex.Hd.Fl.Bzn This part replaces 210251680. |
| 24 |
514053620 |
Heat protector |
| 25 |
605351330 |
Heat protector |
| 26 |
605350745 |
SUPPORT - Call your local BRP dealership |
| 27 |
40053 |
Allen screw M10 x 25 |
| 28 |
570044700 |
Rubber damper |
| 29 |
414115200 |
Tie-Rap 180 mm This part replaces 27026. |
