| Ref | Part Number | Description |
|---|
| BA |
409010100 |
Female Terminal |
| BA |
409010400 |
Female Terminal Housing, 1 Circuit |
| BE |
278000631 |
Male Terminal |
| BE |
278000635 |
Female Housing, 4 Circuits |
| BE |
278000636 |
Female Wedge, 4 Circuits |
| BM |
278000992 |
Open Barrel |
| CF |
293750002 |
Tie Wrap 142 mm |
| CF |
515175231 |
Female Terminal |
| CF |
515175819 |
Female Terminal Housing, 8 Circuits |
| CM |
278002307 |
FEMALE TERMINAL - Call your local BRP dealership |
| CM |
293750002 |
Tie Wrap 142 mm |
| CM |
409209600 |
Female Housing, 3 Circuits |
| CM |
515176621 |
Wire Seal |
| COM |
278000632 |
Female Terminal |
| COM |
293000052 |
Sealing Cap |
| COM |
515175673 |
Male Housing, 6 Circuits |
| COM |
515175678 |
Male Wedge, 6 Circuits |
| CV |
515175801 |
Female Housing, 24 Circuits |
| CV |
515175802 |
Retainer Block |
| CV |
515175803 |
Wire Seal |
| CV |
515175806 |
Female Terminal |
| CV |
515175812 |
Plug |
| CV |
710000399 |
Female Housing |
| CV |
710001131 |
Female Terminal |
| DA |
293740005 |
Tape |
| DA |
293750002 |
Tie Wrap 142 mm |
| DA |
414115200 |
Tie-Rap 180 mm |
| DA |
515175806 |
Female Terminal |
| DA |
515175812 |
Plug |
| DA |
515176221 |
Female Housing |
| DA |
515176222 |
Wire Seal |
| DA |
515176223 |
Female Terminal Housing, 36 Circuits |
| DA |
515176224 |
Terminal Support |
| DA |
515176485 |
Protection Cap |
| DA |
710001131 |
Female Terminal |
| DS |
515175231 |
Female Terminal |
| DS |
515175495 |
Female Housing, 3 Circuits |
| EI |
278000631 |
Male Terminal |
| EI |
409207500 |
Male Lock, 2 Circuits |
| EI |
515175665 |
Male Terminal Housing, 2 Circuits |
| FC |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| FC |
409003900 |
Fuse, 20 Amperes |
| FC |
409004000 |
Fuse Holder |
| FC |
409004200 |
Female Terminal |
| FC |
710000992 |
Clip |
| FD |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| FD |
278000343 |
Fuse, 15 Amperes |
| FD |
409004000 |
Fuse Holder |
| FD |
409004200 |
Female Terminal |
| FD |
710000992 |
Clip |
| HG |
515175231 |
Female Terminal |
| HG |
515175282 |
Female Terminal |
| HG |
515175350 |
Female Terminal Housing, 13 Circuits |
| NE |
515175232 |
Male Terminal |
| NE |
515175654 |
Male Terminal Housing, 2 Circuits |
| NH |
710001164 |
Female Terminal |
| NH |
710001332 |
Seal Wire |
| NV |
515176164 |
Male Terminal |
| NV |
515176621 |
Wire Seal |
| NV |
710000568 |
Housing |
| NV |
710000992 |
Clip |
| PA |
515176909 |
Terminal |
| PB |
515176909 |
Terminal |
| R1 |
293750002 |
Tie Wrap 142 mm |
| R1 |
409209900 |
Female Housing, 5 Circuits |
| R1 |
561503100 |
FEMALE TERMINAL - Call your local BRP dealership |
| R1 |
710010053 |
Relay This part replaces 515177041. |
| RE |
515176530 |
Connector |
| RE |
515176531 |
Terminal |
| RE |
515176594 |
Seal |
| SA |
515175231 |
Female Terminal |
| SA |
515175495 |
Female Housing, 3 Circuits |
| VC |
515175658 |
Female Housing, 2 Circuits |
| 188 |
409902000 |
Tubing 12 mm |
| 420 |
414115200 |
Tie-Rap 180 mm |
| 775 |
293730040 |
Mount Dart |
