| Ref | Part Number | Description |
|---|
| 1 |
0435822 |
GEARCASE & BEARING ASSY. |
| 2 |
0391471 |
BEARING, Pinion |
| 4 |
0333234 |
SCREEN, Water intake, port |
| 5 |
0333233 |
SCREEN, Water intake, stbd |
| 11 |
0334145 |
DETENT, Shifter |
| 15 |
0326823 |
SHAFT |
| 21 |
0431735 |
HOUSING & BEARING ASSY |
| 22 |
0435122 |
GEAR, Forward and pinion |
| 24 |
5000360 |
Hsg Ay This part replaces 0436755. |
| 30 |
0326733 |
THRUST WASHER |
| 32 |
0431704 |
GEAR, Reverse |
| 35 |
0335679 |
DRIVESHAFT, Lower |
| 53 |
0332746 |
SCREW, Anode |
| 54 |
0397768 |
ANODE |
| 60 |
0435772 |
DRIVESHAFT ASSY. |
| 60 |
5000625 |
D'Shaft 25" V/8 This part replaces 0435771. |
| 65 |
0313715 |
SCREW, Cap, hex hd, 7/16-14 x 1 |
| 69 |
0326784 |
WASHER, Screw |
| 70 |
0331998 |
SCREW, Gearcase to housing |
| 72 |
0331999 |
SCREW, Gearcase housing |
| 73 |
0331353 |
Seal, Impeller Housing Plate. |
| 84 |
0326785 |
WASHER |
| 88 |
0331188 |
O-Ring |
| 90 |
0338944 |
TRIM TAB, Gearcase |
| 91 |
0330029 |
SHIFT ROD |
| 91 |
0337553 |
SHIFT ROD |
| 94 |
0435526 |
CHROME CUP & PLATE KIT This part replaces 0395059. |
| 95 |
5006373 |
GEARCASE SEAL KIT This part replaces 0434516. |
| 0436769 |
0436769 |
GEARCASE ASSY., Complete |
