| Ref | Part Number | Description |
|---|
| 350 |
705019974 |
LH Rocker Panel |
| 355 |
293150308 |
Black, Ornit Rivet 3/16 X ,675 This part replaces 293150308. |
| 360 |
250100208 |
Panel Nut M6 X 1.0 |
| 365 |
250000722 |
Torx Screw M6 X 20 |
| 370 |
234062670 |
Stainless Steel Flat Washer |
| 380 |
250200162 |
Flat Washer M6.6 X 22 |
| 450 |
705019975 |
RH Rocker Panel |
| 455 |
293150308 |
Black, Ornit Rivet 3/16 X ,675 This part replaces 293150308. |
| 460 |
250100208 |
Panel Nut M6 X 1.0 |
| 465 |
250000722 |
Torx Screw M6 X 20 |
| 470 |
234062670 |
Stainless Steel Flat Washer |
| 480 |
250200162 |
Flat Washer M6.6 X 22 |
| 500 |
705015962 |
LH Front Mud Guard |
| 510 |
517309511 |
Insulating Washer |
| 520 |
250100208 |
Panel Nut M6 X 1.0 |
| 525 |
250200162 |
Flat Washer M6.6 X 22 |
| 530 |
293150308 |
Black, Ornit Rivet 3/16 X ,675 This part replaces 293150308. |
| 540 |
234062670 |
Stainless Steel Flat Washer |
| 550 |
250000722 |
Torx Screw M6 X 20 |
| 600 |
705015963 |
RH Front Mud Guard |
| 610 |
517309511 |
Insulating Washer |
| 620 |
250100208 |
Panel Nut M6 X 1.0 |
| 625 |
250200162 |
Flat Washer M6.6 X 22 |
| 630 |
293150308 |
Black, Ornit Rivet 3/16 X ,675 This part replaces 293150308. |
| 640 |
234062670 |
Stainless Steel Flat Washer |
| 650 |
250000722 |
Torx Screw M6 X 20 |
| 1600 |
705017474 |
Carbon Black, LH Central Body Panel |
| 1610 |
250000722 |
Torx Screw M6 X 20 |
| 1620 |
234062670 |
Stainless Steel Flat Washer |
| 1630 |
517306478 |
Clip |
| 1700 |
705017475 |
Carbon Black, RH Central Body Panel |
| 1710 |
250000722 |
Torx Screw M6 X 20 |
| 1720 |
234062670 |
Stainless Steel Flat Washer |
| 1730 |
517306478 |
Clip |
| 1800 |
705017767 |
Carbon Black, LH Central Body Panel |
| 1810 |
250000722 |
Torx Screw M6 X 20 |
| 1820 |
234062670 |
Stainless Steel Flat Washer |
| 1830 |
250001165 |
Hex Sems Screw M6X20 |
| 1840 |
250100208 |
Panel Nut M6 X 1.0 |
| 1900 |
705017768 |
Carbon Black, RH Central Body Panel |
| 1910 |
250000722 |
Torx Screw M6 X 20 |
| 1920 |
234062670 |
Stainless Steel Flat Washer |
| 1930 |
250001165 |
Hex Sems Screw M6X20 |
