| Ref | Part Number | Description |
|---|
| 1 |
0582417 |
PLATE & SLEEVE ASSEMBLY |
| 4 |
0319682 |
VIS, capteur vers plaque |
| 6 |
0512743 |
DISPOSITIF DE RETENUE |
| 7 |
0303212 |
VIS, collier & capot |
| 9 |
0511460 |
VIS, dispositif de retenue |
| 10 |
0511458 |
COLLIER, fils |
| 11 |
0331626 |
COVER, Leads |
| 12 |
0585073 |
COIL & LAMINATION ASSY. |
| 15 |
0337522 |
VIS, ensemble bobine |
| 16 |
0582926 |
STATOR |
| 19 |
0514481 |
SLEEVE |
| 20 |
0328074 |
CACHE, cosse prise |
| 21 |
0584528 |
IGNITION MODULE |
| 29 |
0585072 |
SENSOR ASSEMBLY |
| 31 |
0323144 |
SPACER |
| 32 |
0326111 |
NUT |
| 33 |
0306644 |
VIS, capteur de papillon |
| 35 |
0335020 |
SCREW, Bracket to block |
| 39 |
0332063 |
PLATE, Support |
| 40 |
0322435 |
ROULEMENT, plaque d'allumage vers support |
| 41 |
0332070 |
SCREW, Retaining plate This part replaces 0326875. |
| 42 |
0332790 |
RETAINER |
| 43 |
0329110 |
VIS, boîtier d'échappement vers bloc cylindres-carter |
| 44 |
0583740 |
COIL Assy |
| 45 |
0584261 |
FLYWHEEL Assy |
| 48 |
0333757 |
COVER |
| 49 |
0337924 |
BRACKET, Electrical |
| 50 |
0582365 |
H.T. LEAD ASSEMBLY, Spark plugs to ignition coil |
| 57 |
0586020 |
MOTOR CABLE Assy |
| 82 |
0352051 |
BRACKET, Connector This part replaces 0342197. |
| 83 |
0514694 |
BRACKET, Mounting |
| 84 |
0342265 |
COVER, Bracket |
| 85 |
0124880 |
SCREW, Bracket, timing pointer |
| 86 |
0305452 |
SCREEN |
| 89 |
0329513 |
SCREW, Float bowl |
| 90 |
0329182 |
VIS, borne |
| 91 |
0581778 |
REDRESSEUR |
| 93 |
0335655 |
BOUCHON, étanchéité |
