| Ref | Part Number | Description |
|---|
| 9 |
0319682 |
VIS, capteur vers plaque |
| 13 |
0336842 |
CLIP, SPRING This part replaces 0603145. |
| 15 |
0306014 |
VIS, ancrage |
| 17 |
0317501 |
SCREW PLUG, Orifice |
| 18 |
0330056 |
ROLLER, Cam follower |
| 22 |
0327740 |
ORIFICE, No 68 |
| 23 |
0308776 |
O-RING |
| 27 |
0325829 |
HIGH SPEED ORIFICE, No. 42 |
| 30 |
0315232 |
RETAINER , Needle valve stbd |
| 31 |
0330129 |
NEEDLE VALVE |
| 32 |
0325092 |
GASKET |
| 33 |
0316355 |
BUT, Carburetor mounting |
| 0394810 |
0394810 |
CARBURETOR ASSEMBLY, Upper & lower |
| 0394811 |
0394811 |
CARBURETOR ASSEMBLY, middle |
| 0394812 |
0394812 |
CARBURETOR ASSEMBLY, Upper & lower |
| 0394813 |
0394813 |
CARBURETOR ASSEMBLY, middle |
