| Ref | Part Number | Description |
|---|
| 1 |
0901624 |
END PANEL,Port |
| 2 |
0310945 |
PANEL,Port |
| 3 |
0381630 |
AMMETER ASSEMBLY |
| 5 |
0310946 |
PANEL,Starboard |
| 6 |
0379853 |
INDICATING LIGHT ASSY., Temperature |
| 10 |
0975257 |
SWITCH ASSEMBLLY |
| 12 |
0900696 |
WASHER |
| 13 |
0901680 |
NAMEPLATE |
| 16 |
0386545 |
IGNITION SWITCH & KEY ASSY This part replaces 0378238. |
| 21 |
0901625 |
END PANEL,Short |
| 22 |
0901626 |
SCREW,End panel |
| 23 |
0901146 |
SCREW,Dash panel |
| 24 |
0380550 |
INDICATING LIGHT,Ignition |
| 28 |
0309024 |
PLUG |
| 29 |
0901627 |
SPEED NUT |
| 30 |
0901628 |
NUT |
| 31 |
0379682 |
LEAD,Choke to ignition |
| 33 |
0205403 |
PLUG (EVEINRUDE) |
| 33 |
0310982 |
PLUG (OMC) |
| 33 |
0901619 |
PLUG (JOHNSON) |
| 34 |
0378334 |
FUSE HOLDER & LEAD ASSEMBLY |
| 35 |
0380551 |
LEAD,Ignition "on" light to ground |
