| Ref | Part Number | Description |
|---|
| 10a2 |
219704374 |
Gasket 1000Mm Long |
| 10a3 |
269501609 |
Clip |
| 10b |
264000120 |
Storage Bin Cover Ass'y |
| 10b2 |
293250210 |
NEOPRENE SEAL - Call your local BRP dealership |
| 20 |
264000024 |
Latch |
| 400 |
Not |
Available As Spare Part - Not Available |
| 410 |
269500521 |
Hook |
| 420 |
293150027 |
Avdel Rivet |
| 450a |
264000112 |
GLOVE BOX EXT. - Call your local BRP dealership |
| 450b |
219704381 |
SEAL 1000MM LONG - Call your local BRP dealership |
| 460 |
293730011 |
Black, Dart |
| 500b |
264000164 |
Black, Latch This part replaces 264000091. |
| 500c |
293250367 |
GASKET - Call your local BRP dealership |
| 550b |
293830005 |
Rubber Bumper |
| 730 |
269502417 |
Strap This part replaces 269500408. |
| 740 |
269502145 |
Strap |
| 750 |
264000114 |
DOOR COMPARTMENT - Call your local BRP dealership |
| 760 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
