07- Steering _23M1511
Parts (31)
| Ref | Part Number | Description |
|---|---|---|
| 3 | 207004034 | Hex. Screw M10 X 1.5 X 40 |
| 4 | 207005554 | Hex Screw M10 X 1.5 X 55 |
| 5 | 207667056 | Hex. Flange Screw M6 X 70 This part replaces 207667086. |
| 8 | 233201464 | Hex. Flange Elastic M10 x 1.5 |
| 9 | 233261416 | Elastic Flange Nut M6 X 1.0 |
| 11 | 250000352 | Hex. Flange Screw M8 X 40 |
| 12 | 250000779 | Torx Screw M6 X 1.0 X 18, Scotch Grip This part replaces 250000402. |
| 14 | 250100016 | LH Threaded Hex. Jam Nut M10 |
| 16 | 503192496 | Washer |
| 17 | 506152163 | Plate |
| 20 | 506152297 | Housing Bushing |
| 21 | XXX | Not Available As Spare Parts |
| 25 | 506152460 | Moulding Strap |
| 27 | 506152482 | Tie-Rod |
| 28 | 506152508 | Upper Half-Housing |
| 29 | 506152509 | Upper Anti-Vibration Gasket |
| 30 | 506152518 | Lower Vibration Ring |
| 32 | 506153176 | Thermal Insulation This part replaces 506152548. |
| 33 | 506152555 | Steering Support |
| 34 | 506152556 | Steering Support |
| 35 | 506152717 | Steering Pad |
| 36 | 506152560 | Grip 148mm |
| 39 | 506152582 | Washer |
| 40 | 506152962 | Steering Column This part replaces 506152584. |
| 42 | 506152588 | Lower Half-Housing |
| 43 | 506152798 | Heating Element 32 Watt 3 Wires This part replaces 506152665. |
| 52 | 732610010 | RH Threaded Hex. Jam Nut M10 |
| 53 | 506152751 | Steering Support |
| 54 | 233601466 | Elastic Locking Nut M10 |
| 55 | 506152019 | RH Threaded Ball Joint |
| 56 | 506152081 | LH Thread Ball Joint |
