| Ref | Part Number | Description |
|---|
| 15 |
706204639 |
LH Lower Suspension Arm This part replaces 706201874. |
| 17 |
706202870 |
Black, RH Lower Arm This part replaces 706201875. |
| 20 |
703500875 |
Suspension Arm Bushing Kit |
| 50 |
207607046 |
Hex. Flange Screw M10 X 70 |
| 55 |
706202045 |
Ball Joint |
| 56 |
706202044 |
Ball Joint |
| 60 |
233201436 |
Hex. Flange Elastic Nut M10 This part replaces 233201416. |
| 65 |
706200998 |
Front Suspension Cross Plate |
| 70 |
706201797 |
Black RH Upper Arm |
| 80 |
408200700 |
Grease Fitting |
| 85 |
293550056 |
Grease Fitting 90° |
| 100 |
706201796 |
Black LH Upper Arm |
| 110 |
250001038 |
Hex. Flange Screw M10 X 75 This part replaces 207607587. |
| 115 |
233201436 |
Hex. Flange Elastic Nut M10 This part replaces 233201416. |
| 120 |
207605546 |
Hex. Flange Screw M10 X 55 |
| 125 |
233201436 |
Hex. Flange Elastic Nut M10 This part replaces 233201416. |
| 160 |
706202808 |
LH Joint Protector This part replaces 706201829. |
| 160 |
706202809 |
RH Joint Protector This part replaces 706201830. |
| 180 |
250000755 |
Torx Screw M6 X 16 |
| 190 |
233261494 |
Hex. Flange Elastic Nut M6 |
| 195 |
234062670 |
Stainless Steel Flat Washer |
| 230 |
293370035 |
Circlip |
| 236 |
705203247 |
Upper Front Holder |
| 240 |
250100099 |
Nut M12 |
| 241 |
706200281 |
Hardened Washer This part replaces 250200086. |
| 242 |
207606044 |
Hex. Flange Screw M10 X 60 |
| 243 |
233201434 |
Hex. Flange Elastic Nut M10 |
| 250 |
211400017 |
Cotter Pin |
| 280 |
207682534 |
Hex. Flange Screw M8 X 25 |
