07- Body - Decals
Parts (19)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5036915 | CAM, THROTTLE |
| 2 | 5036916 | BRACKET, THROTTLE CABLE |
| 3 | 5034142 | RONDELLE (6,5 x 20 x 2,0 mm) |
| 4 | 5031236 | SPACER |
| 7 | 5036917 | BRACKET, Neutral safety cable |
| 10 | 516010651 | BRP Logo 20 MM x 2 MM |
| 15 | 704909040 | Emblem BRP Logo 48 MM UV |
| 30 | 704909040 | Emblem BRP Logo 48 MM UV |
| 100 | 516009698 | Hood Decal "Turbo" |
| 200 | 516011005 | Upper Side Panel Decal |
| 220 | 516010670 | LH/RH Front Hood Decal |
| 300 | 516010678 | LH/RH Side Panel Decal |
| 310 | 516010980 | LH/RH Side Panel Decal |
| 600 | 516008760 | Decal "Rotax Power" |
| 700 | 516010668 | LH/RH Frame Decal |
| 800 | 516010669 | LH/RH Platform Decal |
| 1130 | 516011629 | Tool Instruction Label |
| 1535 | 516009954 | Protective Decal |
| 1580 | 516009928 | Suspension Adjustment Decal |
