| Ref | Part Number | Description |
|---|
| BLS |
409209500 |
Female Housing, 2 Circuits |
| BLS |
515176621 |
Wire Seal |
| BLS |
710001340 |
Female Terminal |
| CES |
515175231 |
Female Terminal |
| CES |
515175658 |
Female Housing, 2 Circuits |
| CF |
278000217 |
Female Housing, 2 Circuits |
| CF |
409004300 |
Male Terminal |
| CF |
710000504 |
Wire Seal |
| CL |
515175801 |
Female Housing, 24 Circuits |
| CL |
515175802 |
Retainer Block |
| CL |
515175803 |
Wire Seal |
| CL |
515175804 |
BLOCK - Call your local BRP dealership |
| CL |
515175806 |
Female Terminal |
| CL |
515175812 |
Plug |
| CL |
710001131 |
Female Terminal |
| CSV |
278000998 |
Female Terminal |
| CSV |
415128500 |
Female Terminal Housing, 2 Circuits |
| CSV |
415128501 |
Seal |
| D2 |
409012700 |
Diode |
| DC1 |
409010100 |
Female Terminal |
| DC1 |
409010400 |
Female Terminal Housing, 1 Circuit |
| DC2 |
409010100 |
Female Terminal |
| DC2 |
409010400 |
Female Terminal Housing, 1 Circuit |
| DC2 |
414115200 |
Tie-Rap 180 mm |
| DC2 |
710000670 |
CAP - Call your local BRP dealership |
| DC3 |
515175231 |
Female Terminal |
| DC3 |
515175658 |
Female Housing, 2 Circuits |
| DC3 |
710000667 |
Male Housing, 2 Circuits |
| DLC |
278001665 |
Female Terminal |
| DLC |
515175673 |
Male Housing, 6 Circuits |
| DLC |
515175678 |
Male Wedge, 6 Circuits |
| DPS1 |
710001114 |
Cap |
| DPS1 |
710001161 |
Housing |
| DPS1 |
710001162 |
Lock |
| DPS1 |
710001163 |
Wire Seal |
| DPS1 |
710001164 |
Female Terminal |
| DPS1 |
710001225 |
Cap |
| DPS2 |
710001160 |
Female Terminal |
| DPS2 |
710001315 |
HOUSING - Call your local BRP dealership |
| DPS2 |
710001935 |
SEAL - Call your local BRP dealership |
| ECMB |
278001750 |
FEMALE TERMINAL - Call your local BRP dealership |
| ECMB |
278001751 |
MALE HOUSING, 41 CIRCUITS - Call your local BRP dealership |
| ECMB |
293750002 |
Tie Wrap 142 mm |
| ECMB |
515175883 |
Latch |
| ECMB |
515175884 |
LOCK - Call your local BRP dealership |
| ECMB |
515175885 |
COVER - Call your local BRP dealership |
| ECMB |
515175886 |
SEAL - Call your local BRP dealership |
| EOP |
409010100 |
Female Terminal |
| EOP |
409010400 |
Female Terminal Housing, 1 Circuit |
| EVAP |
710001135 |
Wire Seal |
| EVAP |
710001136 |
Housing |
| EVAP |
710001137 |
Female Terminal |
| FB |
278000999 |
Wire Seal |
| FB |
278002172 |
Foam |
| FB |
415128501 |
Seal |
| FB |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| FB |
515176774 |
Relay, 30 AMP |
| FB |
710000742 |
Little Fuse, 5 Amperes |
| FB |
710000744 |
Little Fuse, 10 Amperes |
| FB |
710000745 |
Little Fuse, 15 Ampere |
| FB |
710000781 |
Fuse Puller |
| FB |
710000836 |
Female Terminal |
| FB |
710000840 |
Cap |
| FB |
710000968 |
FUSE DECAL - Call your local BRP dealership |
| FB |
710001008 |
Little Fuse, 3 AMP |
| FB |
710001026 |
Fuse Cover |
| FLF |
409209500 |
Female Housing, 2 Circuits |
| FLF |
515176621 |
Wire Seal |
| FLF |
710001340 |
Female Terminal |
| FP |
278001482 |
Seal |
| FP |
710001132 |
Housing |
| FP |
710001133 |
Lock |
| FP |
710001134 |
Female Terminal |
| FPL1 |
409209400 |
Male Terminal Housing, 2 Circuits |
| FPL1 |
414115200 |
Tie-Rap 180 mm |
| FPL1 |
515176164 |
Male Terminal |
| FPL1 |
515176621 |
Wire Seal |
| FPL1 |
710001949 |
GROMMET - Call your local BRP dealership |
| FPL2 |
409209400 |
Male Terminal Housing, 2 Circuits |
| FPL2 |
414115200 |
Tie-Rap 180 mm |
| FPL2 |
515176164 |
Male Terminal |
| FPL2 |
515176621 |
Wire Seal |
| FPL2 |
710001949 |
GROMMET - Call your local BRP dealership |
| FRF |
409209500 |
Female Housing, 2 Circuits |
| FRF |
515176621 |
Wire Seal |
| FRF |
710001340 |
Female Terminal |
| GBPS |
278000997 |
Male Housing, 3 Circuits |
| GBPS |
278001210 |
FEMALE TERMINAL - Call your local BRP dealership |
| GBPS |
415128501 |
Seal |
| GND |
710000913 |
Terminal |
| HBS |
409013700 |
Plug |
| HBS |
409209600 |
Female Housing, 3 Circuits |
| HBS |
515176621 |
Wire Seal |
| HBS |
710001340 |
Female Terminal |
| HIC |
278001665 |
Female Terminal |
| HIC |
515175673 |
Male Housing, 6 Circuits |
| HIC |
515175678 |
Male Wedge, 6 Circuits |
| HLC |
278001665 |
Female Terminal |
| HLC |
515175673 |
Male Housing, 6 Circuits |
| HLC |
515175678 |
Male Wedge, 6 Circuits |
| HN1 |
409010100 |
Female Terminal |
| HN1 |
409010400 |
Female Terminal Housing, 1 Circuit |
| HN2 |
409010100 |
Female Terminal |
| HN2 |
409010400 |
Female Terminal Housing, 1 Circuit |
| HO2S |
409004800 |
FEMALE TERMINAL - Call your local BRP dealership |
| HO2S |
409005400 |
Wire Seal |
| HO2S |
710001138 |
Housing |
| HO2S |
710001139 |
Lock |
| HO2S |
710001140 |
Female Terminal |
| IK |
414115200 |
Tie-Rap 180 mm |
| IK |
710001128 |
HOUSING - Call your local BRP dealership |
| IK |
710001130 |
FEMALE TERMINAL - Call your local BRP dealership |
| IK |
710001338 |
CAP - Call your local BRP dealership |
| LPS |
409013700 |
Plug |
| LPS |
409209600 |
Female Housing, 3 Circuits |
| LPS |
515176621 |
Wire Seal |
| LPS |
710001340 |
Female Terminal |
| MFB34 |
710001051 |
MALE TERMINAL - Call your local BRP dealership |
| MFB34 |
710001057 |
FUSE HOLDER - Call your local BRP dealership |
| MFB56 |
710001051 |
MALE TERMINAL - Call your local BRP dealership |
| MFB56 |
710001054 |
FUSE HOLDER - Call your local BRP dealership |
| MFB78 |
710001050 |
MALE TERMINAL - Call your local BRP dealership |
| MFB78 |
710001055 |
FUSE HOLDER - Call your local BRP dealership |
| MSL |
515175808 |
FEMALE TERMINAL - Call your local BRP dealership |
| MSL |
515175941 |
Female Terminal |
| MSL |
710001126 |
Housing |
| MSL |
710001127 |
Lock |
| MSR |
515175941 |
Female Terminal |
| MSR |
710001124 |
HOUSING - Call your local BRP dealership |
| MSR |
710001125 |
LOCK - Call your local BRP dealership |
| OLS1 |
278001113 |
Male Connector, 2 Circuits |
| OLS1 |
710001119 |
Female Terminal |
| OLS2 |
278001113 |
Male Connector, 2 Circuits |
| OLS2 |
710001119 |
Female Terminal |
| PL |
409209400 |
Male Terminal Housing, 2 Circuits |
| PL |
414115200 |
Tie-Rap 180 mm |
| PL |
515176164 |
Male Terminal |
| PL |
515176621 |
Wire Seal |
| PL |
710001950 |
GROMMET - Call your local BRP dealership |
| PL |
710002033 |
Connector Holder |
| PRS |
409207600 |
Male Lock, 3 Circuits |
| PRS |
515175666 |
Male Housing |
| PRS |
710001348 |
Male Terminal |
| RLF1 |
278001012 |
Male Housing, 1 Circuit |
| RLF1 |
515176621 |
Wire Seal |
| RLF1 |
710001340 |
Female Terminal |
| RLF2 |
278001012 |
Male Housing, 1 Circuit |
| RLF2 |
515176621 |
Wire Seal |
| RLF2 |
710001340 |
Female Terminal |
| RRF1 |
278001012 |
Male Housing, 1 Circuit |
| RRF1 |
515176621 |
Wire Seal |
| RRF1 |
710001340 |
Female Terminal |
| RRF2 |
278001012 |
Male Housing, 1 Circuit |
| RRF2 |
515176621 |
Wire Seal |
| RRF2 |
710001340 |
Female Terminal |
| SAS |
710001117 |
FEMALE TERMINAL - Call your local BRP dealership |
| SAS |
710001118 |
Wire Seal |
| SAS |
710003730 |
Housing This part replaces 710001120. |
| STS1 |
409010100 |
Female Terminal |
| STS1 |
409010400 |
Female Terminal Housing, 1 Circuit |
| STS2 |
409010100 |
Female Terminal |
| STS2 |
409010400 |
Female Terminal Housing, 1 Circuit |
| TL1 |
409209600 |
Female Housing, 3 Circuits |
| TL1 |
515176621 |
Wire Seal |
| TL1 |
710001340 |
Female Terminal |
| TL2 |
409209600 |
Female Housing, 3 Circuits |
| TL2 |
515176621 |
Wire Seal |
| TL2 |
710001340 |
Female Terminal |
| VCM |
293750002 |
Tie Wrap 142 mm |
| VCM |
710001867 |
TERMINAL - Call your local BRP dealership |
| VCM |
710001869 |
Terminal |
| VCM |
710001870 |
MOLEX HOUSING, 38 PINS - Call your local BRP dealership |
| VCM |
710001871 |
Molex Lock, 38 Pins |
| VCM |
710001879 |
PLUG - Call your local BRP dealership |
| VCM |
710001880 |
Seal |
| VCM |
710001884 |
PLUG - Call your local BRP dealership |
| VCM |
710002032 |
MOLEX CONNECTOR COVER - Call your local BRP dealership |
| VIM1 |
409013700 |
Plug |
| VIM1 |
515176164 |
Male Terminal |
| VIM1 |
515176621 |
Wire Seal |
| VIM1 |
710000576 |
HOUSING, 4CIRCUITS - Call your local BRP dealership |
| VIM2 |
409209700 |
Female Housing, 4 Circuits |
| VIM2 |
515176621 |
Wire Seal |
| VIM2 |
710001340 |
Female Terminal |
| VR1 |
710000877 |
Female Terminal |
| VR1 |
710000879 |
Female Housing, 3 Circuits |
| VR1 |
710000881 |
Seal |
| VR1 |
710000882 |
Cap |
| VSS1 |
710001117 |
FEMALE TERMINAL - Call your local BRP dealership |
| VSS1 |
710001118 |
Wire Seal |
| VSS1 |
710003729 |
Housing This part replaces 710001116. |
| VSS2 |
710001117 |
FEMALE TERMINAL - Call your local BRP dealership |
| VSS2 |
710001118 |
Wire Seal |
| VSS2 |
710003729 |
Housing This part replaces 710001116. |
| VSS4 |
710001117 |
FEMALE TERMINAL - Call your local BRP dealership |
| VSS4 |
710001118 |
Wire Seal |
| VSS4 |
710003729 |
Housing This part replaces 710001116. |
| YRS |
710001117 |
FEMALE TERMINAL - Call your local BRP dealership |
| YRS |
710001118 |
Wire Seal |
| 188 |
409902000 |
Tubing 12 mm |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 254 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 255 |
219704400 |
Was 409901800 Tubing (13 mm) |
| 256 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 257 |
219704398 |
Was 409901600 Tubing 19mm |
| 258 |
219704407 |
Tubing 10 MM 1000MM Long |
| 260 |
219704423 |
Was 515175319 Tubing 22 mm |
| 331 |
219704446 |
PROTECTOR TUBE, 4MM 1000MM LONG - Call your local BRP dealership |
| 426 |
219704427 |
LOW TEMPERATURE TUBING 1/2? 3000MM LONG - Call your local BRP dealership |
