| Ref | Part Number | Description |
|---|
| 1 |
219904010 |
WARNING DECAL - Call your local BRP dealership |
| 2 |
219904018 |
SEA-DOO DECAL - Call your local BRP dealership |
| 4 |
262000044 |
COUPLER - Call your local BRP dealership |
| 5 |
262000045 |
SAFETY CABLE - Call your local BRP dealership |
| 16 |
269800305 |
HEX. CAP SCREW 3/8 -16 X 1 - Call your local BRP dealership This part replaces 269800005. |
| 17 |
269800078 |
WINCH - Call your local BRP dealership |
| 17 |
296000328 |
WINCH STRAP - Call your local BRP dealership |
| 18 |
269800401 |
HEX. BOLT 1/2''-13 X 4'' - Call your local BRP dealership This part replaces 269800131. |
| 19 |
269800132 |
HEXAGONAL BOLT - Call your local BRP dealership |
| 20 |
269800160 |
Lock Nut |
| 21 |
269800169 |
BOW ROLLER - Call your local BRP dealership |
| 22 |
296000429 |
GROMMET - Call your local BRP dealership |
| 23 |
269800184 |
WASHER - Call your local BRP dealership |
| 24 |
269800299 |
CENTERLOCK NUT - Call your local BRP dealership |
| 25 |
269800300 |
FLAT WASHER - Call your local BRP dealership |
| 26 |
269800305 |
HEX. CAP SCREW 3/8 -16 X 1 - Call your local BRP dealership |
| 27 |
269800309 |
WASHER 1/2'' - Call your local BRP dealership |
| 28 |
269800310 |
CENTERLOCK NUT 1/2-1 - Call your local BRP dealership |
| 29 |
269800401 |
HEX. BOLT 1/2''-13 X 4'' - Call your local BRP dealership |
| 30 |
269800462 |
HEX. BOLT - Call your local BRP dealership |
| 31 |
269800480 |
U-BOLT 3/8''-16 X 3-1/8'' X 2-3/8'' - Call your local BRP dealership |
| 33 |
269800492 |
CENTER LOCK NUT 7/16'' - Call your local BRP dealership |
| 34 |
269800493 |
HEX. SOCKET SCREW 1/4'-20 X 1-1/2'' - Call your local BRP dealership |
| 35 |
269800495 |
U-BOLT 1/2''-13 X 2-1/16'' X 4-1/2'' - Call your local BRP dealership |
| 36 |
269800575 |
END CAP - Call your local BRP dealership |
| 43 |
291003781 |
LH FENDER TRAILER, GREY - Call your local BRP dealership |
| 43 |
291003844 |
LH FENDER TRAILER, BLACK - Call your local BRP dealership |
| 44 |
291003782 |
RH FENDER TRAILER, GREY - Call your local BRP dealership |
