| Ref | Part Number | Description |
|---|
| 21 |
409004800 |
FEMALE TERMINAL - Call your local BRP dealership |
| 32 |
278000998 |
Female Terminal |
| 33 |
278000999 |
Wire Seal |
| 34 |
409010100 |
Female Terminal |
| 36 |
409010400 |
Female Terminal Housing, 1 Circuit |
| 44 |
515175231 |
Female Terminal |
| 61 |
409012900 |
Male Terminal |
| 62 |
278001014 |
Female Terminal |
| 65 |
710000576 |
HOUSING, 4CIRCUITS - Call your local BRP dealership |
| 68 |
409209500 |
Female Housing, 2 Circuits |
| 69 |
409209600 |
Female Housing, 3 Circuits |
| 70 |
409209700 |
Female Housing, 4 Circuits |
| 73 |
278001013 |
Wire Seal |
| 74 |
409013700 |
Plug |
| 107 |
278000997 |
Male Housing, 3 Circuits |
| 112 |
278000632 |
Female Terminal |
| 127 |
409207600 |
Male Lock, 3 Circuits |
| 186 |
219704424 |
Vinyl Tubing, Low Temp 3000Mm Long |
| 188 |
409902000 |
Tubing 12 mm |
| 196 |
293750002 |
Tie Wrap 142 mm |
| 203 |
278001113 |
Male Connector, 2 Circuits |
| 227 |
409004300 |
Male Terminal |
| 231 |
278000217 |
Female Housing, 2 Circuits |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 254 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 255 |
219704400 |
Was 409901800 Tubing (13 mm) |
| 256 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 257 |
219704398 |
Was 409901600 Tubing 19mm |
| 258 |
219704407 |
Tubing 10 MM 1000MM Long |
| 260 |
219704423 |
Was 515175319 Tubing 22 mm |
| 301 |
409012700 |
Diode |
| 331 |
219704446 |
PROTECTOR TUBE, 4MM 1000MM LONG - Call your local BRP dealership |
| 339 |
278001012 |
Male Housing, 1 Circuit |
| 355 |
515175658 |
Female Housing, 2 Circuits |
| 359 |
515175666 |
Male Housing |
| 365 |
515175672 |
CONNECTOR_MALE 4 CAVITIES - Call your local BRP dealership |
| 366 |
515175673 |
Male Housing, 6 Circuits |
| 370 |
515175677 |
MALE WEDGE, 4 CIRCUITS - Call your local BRP dealership |
| 371 |
515175678 |
Male Wedge, 6 Circuits |
| 387 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| 388 |
278001750 |
FEMALE TERMINAL - Call your local BRP dealership |
| 391 |
278001751 |
MALE HOUSING, 41 CIRCUITS - Call your local BRP dealership |
| 405 |
515175808 |
FEMALE TERMINAL - Call your local BRP dealership |
| 409 |
515175812 |
Plug |
| 410 |
515175801 |
Female Housing, 24 Circuits |
| 411 |
515175802 |
Retainer Block |
| 412 |
515175803 |
Wire Seal |
| 413 |
515175804 |
BLOCK - Call your local BRP dealership |
| 420 |
414115200 |
Tie-Rap 180 mm |
| 426 |
219704427 |
LOW TEMPERATURE TUBING 1/2? 3000MM LONG - Call your local BRP dealership |
| 437 |
515175886 |
SEAL - Call your local BRP dealership |
| 438 |
515175883 |
Latch |
| 439 |
515175884 |
LOCK - Call your local BRP dealership |
| 440 |
515175885 |
COVER - Call your local BRP dealership |
| 460 |
515175941 |
Female Terminal |
| 475 |
710000643 |
Seal |
| 476 |
278001482 |
Seal |
| 481 |
415128500 |
Female Terminal Housing, 2 Circuits |
| 484 |
415128501 |
Seal |
| 524 |
512059668 |
Heat Shrink Tubing 25 mm |
| 538 |
278001210 |
FEMALE TERMINAL - Call your local BRP dealership |
| 579 |
710000504 |
Wire Seal |
| 596 |
710000670 |
CAP - Call your local BRP dealership |
| 641 |
710000667 |
Male Housing, 2 Circuits |
| 645 |
515176164 |
Male Terminal |
| 666 |
710000742 |
Little Fuse, 5 Amperes |
| 668 |
710000744 |
Little Fuse, 10 Amperes |
| 669 |
710000745 |
Little Fuse, 15 Ampere |
| 675 |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| 684 |
710000781 |
Fuse Puller |
| 702 |
710000836 |
Female Terminal |
| 703 |
710000837 |
Female Terminal |
| 706 |
710000840 |
Cap |
| 732 |
710000877 |
Female Terminal |
| 734 |
710000879 |
Female Housing, 3 Circuits |
| 736 |
710000881 |
Seal |
| 737 |
710000882 |
Cap |
| 750 |
710000913 |
Terminal |
| 766 |
278002164 |
FEMALE TERMINAL - Call your local BRP dealership |
| 770 |
710001008 |
Little Fuse, 3 AMP |
| 771 |
515176774 |
Relay, 30 AMP |
| 773 |
710001026 |
Fuse Cover |
| 784 |
710001050 |
MALE TERMINAL - Call your local BRP dealership |
| 785 |
710001051 |
MALE TERMINAL - Call your local BRP dealership |
| 788 |
710001054 |
FUSE HOLDER - Call your local BRP dealership |
| 789 |
710001055 |
FUSE HOLDER - Call your local BRP dealership |
| 790 |
710001057 |
FUSE HOLDER - Call your local BRP dealership |
| 805 |
710001132 |
Housing |
| 806 |
710001133 |
Lock |
| 807 |
710001134 |
Female Terminal |
| 808 |
710001138 |
Housing |
| 809 |
710001139 |
Lock |
| 810 |
710001140 |
Female Terminal |
| 811 |
710001124 |
HOUSING - Call your local BRP dealership |
| 812 |
710001125 |
LOCK - Call your local BRP dealership |
| 813 |
710001126 |
Housing |
| 814 |
710001127 |
Lock |
| 815 |
710001121 |
Female Terminal |
| 816 |
710003729 |
Housing This part replaces 710001116. |
| 817 |
710001117 |
FEMALE TERMINAL - Call your local BRP dealership |
| 818 |
710001118 |
Wire Seal |
| 820 |
710001128 |
HOUSING - Call your local BRP dealership |
| 822 |
710001122 |
HOUSING - Call your local BRP dealership |
| 823 |
710001123 |
HOUSING - Call your local BRP dealership |
| 824 |
710001136 |
Housing |
| 825 |
710001135 |
Wire Seal |
| 826 |
710001137 |
Female Terminal |
| 827 |
710001119 |
Female Terminal |
| 828 |
710003730 |
Housing This part replaces 710001120. |
| 830 |
710001130 |
FEMALE TERMINAL - Call your local BRP dealership |
| 831 |
710001131 |
Female Terminal |
| 835 |
710001141 |
WIRE SEAL - Call your local BRP dealership |
| 847 |
710001157 |
Housing |
| 849 |
710001159 |
Wire Seal |
| 850 |
710001160 |
Female Terminal |
| 851 |
710001161 |
Housing |
| 852 |
710001162 |
Lock |
| 853 |
710001163 |
Wire Seal |
| 854 |
710001164 |
Female Terminal |
| 875 |
710000968 |
FUSE DECAL - Call your local BRP dealership |
| 880 |
710001114 |
Cap |
| 894 |
710001225 |
Cap |
| 915 |
710001315 |
HOUSING - Call your local BRP dealership |
| 921 |
710001340 |
Female Terminal |
| 928 |
710001348 |
Male Terminal |
| 933 |
710001338 |
CAP - Call your local BRP dealership |
| 946 |
278002172 |
Foam |
