| Ref | Part Number | Description |
|---|
| 10 |
277001952 |
Steering |
| 20 |
277001874 |
Wear Ring |
| 110 |
277002165 |
Mango Orange, Handlebar Trim |
| 110 |
277002166 |
Reef Blue, Handlebar Trim |
| 160 |
250001138 |
Plastite Screw Torx Cone HD.M6.81X3 |
| 165 |
211000023 |
Hex. Screw 10-14 X 7/8” |
| 180 |
277001900 |
Deep Black, LH Cover |
| 190 |
277001887 |
Red, Knob Switch |
| 200 |
277002138 |
Hand Lever Accelerator |
| 210 |
293900091 |
Bushing |
| 220 |
241142560 |
Hex. Flange Screw K40 X 25 |
| 230 |
234042600 |
Flat Washer 4 mm, Stainless |
| 235 |
241142560 |
Hex. Flange Screw K40 X 25 |
| 236 |
234042600 |
Flat Washer 4 mm, Stainless |
| 240 |
277001945 |
Reverse Handle |
| 250 |
293900091 |
Bushing |
| 260 |
241142560 |
Hex. Flange Screw K40 X 25 |
| 270 |
234042600 |
Flat Washer 4 mm, Stainless |
| 275 |
241142560 |
Hex. Flange Screw K40 X 25 |
| 276 |
234042600 |
Flat Washer 4 mm, Stainless |
| 310 |
250001138 |
Plastite Screw Torx Cone HD.M6.81X3 |
| 315 |
211000023 |
Hex. Screw 10-14 X 7/8” |
| 330 |
277001788 |
Deep Black, RH Cover |
| 360 |
277001946 |
Deep Black, RH Handle Grip |
| 365 |
277001958 |
Deep Black, LH Handle Grip |
| 380 |
250001138 |
Plastite Screw Torx Cone HD.M6.81X3 |
| 460b1 |
232561200 |
Brass Elastic Stop Nut M6 |
| 465 |
232561200 |
Brass Elastic Stop Nut M6 |
| 470 |
277001654 |
Spacer |
| 480 |
207163560 |
Hex. Screw M6 X 35 |
| 490 |
234062600 |
Flat Washer M6, Stainless |
| 500 |
207064060 |
Hex. Screw M6 X 40 |
| 510 |
234061600 |
Stainless Flat Washer M6 |
| 530 |
277001180 |
Ball Joint |
| 540a |
211100056 |
Hex. Nut 1/4"-28 |
| 540b |
277001582 |
Wiper Rod |
| 540c |
277001583 |
End Piece |
| 545 |
211100056 |
Hex. Nut 1/4"-28 |
| 550 |
276000446 |
Sheat Corrugated 19 MM ID |
| 554 |
277001582 |
Wiper Rod |
| 555 |
277001583 |
End Piece |
| 560 |
293830063 |
Rubber Washer |
| 570 |
277001856 |
Ring Halves |
| 580 |
232561200 |
Brass Elastic Stop Nut M6 |
| 590 |
234061600 |
Stainless Flat Washer M6 |
| 630 |
277000775 |
Ball Joint |
| 640a |
250000969 |
Hex Screw SEMS M6X35, SS |
| 650 |
232561200 |
Brass Elastic Stop Nut M6 |
| 670 |
234061600 |
Stainless Flat Washer M6 |
| 680 |
293300176 |
O-Ring |
| 690 |
250000879 |
Plastite Torx Screw M6.81X30 |
