07- Drive System, Front _12C1505a

07- Drive System, Front _12C1505a

Parts (40)

RefPart NumberDescription
1 207582044 Hex. Flange Screw M8 X 20, Scotch Grip
2 207602544 Hex. Flange Screw M10 X 25
3 230602546 Hex. Flange Screw M10 X 125
4 232291413 Hex. Flange Castellated Nut M18 This part replaces 250100047.
5 233201414 Hex. Flange Elastic Nut M10
6 233201436 Hex. Flange Elastic Nut M10 This part replaces 233201416.
7 XXX Not Available As Spare Parts
12 250200171 Conical Spring Washer M18 This part replaces 250200049.
14 250400036 Cotter Pin
15 293000110 Valve Cap
16 293250246 O-Ring
17 293350150 Ball Bearing This part replaces 293350040.
18 293370019 Circlip
20 703500815 Grease Fitting
22 293750002 Tie Wrap 142 mm
23 503032900 Washer
24 703500813 GREASE FITTING - Call your local BRP dealership
25 715900183 U-Joint
26 715900325 Ens. Croix*U-Joint Cross Kit This part replaces 703500814.
27 705400036 Wear Ring
30 715900116 Fixed Yoke Joint
34 250300060 Wheel Stud This part replaces 250300051.
38 XXX Not Available As Spare Parts
42 XXX Not Available As Spare Parts
65 705402041 Drive Axle Ass'y This part replaces 705401495.
70 715900117 SNAP RING - Call your local BRP dealership
71 715900183 U-Joint
72 703500813 GREASE FITTING - Call your local BRP dealership
75 705402066 Axle Drive Ass'y This part replaces 705401239.
77 705501900 Wheel Hub
78 XXX Not Available As Spare Parts
80 705401646 Ball Bearing
87 705401548 LH Front Knuckle
87 705401549 RH Front Knuckle
109 705500504 Fill Level Plug
110 705500506 Copper Washer
117 219704410 Polyurethane Hose 10000Mm Long
122 715900117 SNAP RING - Call your local BRP dealership
123 715900325 Ens. Croix*U-Joint Cross Kit This part replaces 703500814.
124 703500815 Grease Fitting
