| Ref | Part Number | Description |
|---|
| 1 |
204470908 |
LATERAL LIGHT KIT - Call your local BRP dealership |
| 2 |
209941960 |
PHILLIPS SCREW M4.2 X 19 - Call your local BRP dealership |
| 4 |
204470642 |
REAR LAMP BASE ASSY - Call your local BRP dealership |
| 5 |
204470642 |
REAR LAMP BASE ASSY - Call your local BRP dealership This part replaces 204470643. |
| 6 |
278000217 |
Female Housing, 2 Circuits |
| 7 |
278000222 |
Male Terminal |
| 8 |
278000218 |
Wire Seal |
| 10 |
209943260 |
Phillips Tapping Screw M4.2 X 32 |
| 12 |
204470981 |
RADIO SUPPORT - Call your local BRP dealership |
| 13 |
208462060 |
PHILLIPS SCREW M6 X 20 - Call your local BRP dealership |
| 14 |
234062600 |
Flat Washer M6, Stainless |
| 15 |
232561600 |
Hex. Elastic Stop Nut M6 |
| 16 |
204471304 |
RADIO CD PLAYER COVER - Call your local BRP dealership |
| 17 |
209632560 |
Pan Head Tapping Screw M3.5x25 |
| 18 |
209641360 |
TAPPING PHILLIPS SCREW M4.2 X 13 - Call your local BRP dealership |
| 20 |
204470053 |
Bulb |
| 26 |
204050326 |
SPLIT LOOM 3/8, METER - Call your local BRP dealership |
| 27 |
293750001 |
Tie Wrap 94 mm |
