| Ref | Part Number | Description |
|---|
| 1 |
0986082 |
PARTIAL ENGINE |
| 1 |
3853892 |
PARTIAL ENGINE This part replaces 0986083. |
| 2 |
3853007 |
DOWEL, Cylinder head This part replaces 0914133. |
| 3 |
3852650 |
PLUG, Core hole This part replaces 0912932. |
| 4 |
3853008 |
PLUG, Oil level hole This part replaces 0914134. |
| 5 |
3853108 |
PLUG, Oil gallery This part replaces 0914249. |
| 6 |
3853008 |
PLUG, Oil level hole This part replaces 0914134. |
| 7 |
3852766 |
PLUG, Rear, cam, standard This part replaces 0913704. |
| 7 |
3853009 |
PLUG, Rear, cam, 0.60 in. O.S. This part replaces 0914135. |
| 8 |
3853076 |
DOWEL, Adapter to block This part replaces 0914206. |
| 9 |
3853065 |
BOLT, Main cap This part replaces 0914195. |
| 10 |
3853066 |
STUD, Main cap This part replaces 0914196. |
| 10 |
504154289 |
Deep Black, Chain Case Ass'y |
| 11 |
3853026 |
NUT, Main cap This part replaces 0914153. |
| 12 |
3853010 |
PLUG, Oil gallery This part replaces 0914136. |
| 13 |
3852792 |
CRANKSHAFT This part replaces 0913732. |
| 14 |
3853844 |
RING SET, 0.020 in. O.S. This part replaces 0985123. |
| 14 |
3853879 |
RING SET, 0.030 in. O.S. This part replaces 0985821. |
| 14 |
3853885 |
RING SET, 0.040 in. O.S. This part replaces 0985971. |
| 14 |
3853900 |
RING SET, Standard This part replaces 0986091. |
| 15 |
3853846 |
PISTON ASSY., 0.003 in. O.S. This part replaces 0985155. |
| 15 |
3853876 |
PISTON ASSY., 0.020 in. O.S. This part replaces 0985818. |
| 15 |
3853878 |
PISTON ASSY., 0.040 in. O.S. This part replaces 0985820. |
| 15 |
3857019 |
Piston Ay. This part replaces 0986088. |
| 15 |
3857020 |
Piston Ay. This part replaces 0986087. |
| 15 |
3857022 |
Piston Ay. This part replaces 0985819. |
| 16 |
3852773 |
PIN, Piston, standard This part replaces 0913712. |
| 17 |
3852775 |
BEARING, Rod, standard This part replaces 0913714. |
| 17 |
3853039 |
BEARING, Rod, 0.001 in. U.S. This part replaces 0914169. |
| 17 |
3853040 |
BEARING, Rod, 0.002 in. U.S. This part replaces 0914170. |
| 17 |
3853041 |
BEARING, Rod, 0.010 in. U.S. This part replaces 0914171. |
| 17 |
3853042 |
BEARING, Rod, 0.020 in. U.S. This part replaces 0914172. |
| 17 |
3853043 |
BEARING, Rod, 0.030 in. U.S. This part replaces 0914173. |
| 17 |
3853044 |
BEARING, Rod, 0.040 in. U.S. This part replaces 0914174. |
| 18 |
3853901 |
CONNECTING ROD This part replaces 0986092. |
| 19 |
3852777 |
NUT, Connecting rod This part replaces 0913716. |
| 20 |
250001213 |
Socket Head Screw M6 X 18 |
| 20 |
3852776 |
BOLT, Connecting rod This part replaces 0913715. |
| 21 |
0913717 |
CAMSHAFT |
| 21 |
3852778 |
CAMSHAFT This part replaces 0913718. |
| 22 |
3853045 |
BRG., Main, upper, 0.001 in. U.S. This part replaces 0914175. |
| 22 |
3853046 |
BRG., Main, upper, 0.002 in. U.S. This part replaces 0914176. |
| 22 |
3853048 |
BRG., Main, upper, 0.020 in. U.S. This part replaces 0914178. |
| 22 |
3853049 |
BRG., Main, upper, 0.030 in. U.S. This part replaces 0914179. |
| 22 |
3858945 |
Bearing Kit This part replaces 0913737. |
| 22 |
3858946 |
Main Brg Kit .010 This part replaces 0914177. |
| 23 |
3853050 |
BRG., Main, lower, 0.001 in. U.S. This part replaces 0914180. |
| 23 |
3853051 |
BRG., Main, lower, 0.002 in. U.S. This part replaces 0914181. |
| 23 |
3853053 |
BRG., Main, lower, 0.020 in. U.S. This part replaces 0914183. |
| 23 |
3853054 |
BRG., Main, lower, 0.030 in. U.S. This part replaces 0914184. |
| 23 |
3858945 |
Bearing Kit This part replaces 0913738. |
| 23 |
3858946 |
Main Brg Kit .010 This part replaces 0914182. |
| 24 |
0915918 |
CABLE CLAMP This part replaces 0914740. |
| 24 |
3853060 |
BEARING, Main, center, lower, 0.001 in. U.S. This part replaces 0914190. |
| 24 |
3853061 |
BEARING, Main, center, lower, 0.002 in. U.S. This part replaces 0914191. |
| 24 |
3853063 |
BEARING, Main, center, lower, 0.020 in. U.S. This part replaces 0914193. |
| 24 |
3853064 |
BEARING, Main, center, lower, 0.030 in. U.S. This part replaces 0914194. |
| 24 |
3858946 |
Main Brg Kit .010 This part replaces 0914192. |
| 25 |
3853055 |
BEARING, Main, center, upper, 0.001 in. U.S. This part replaces 0914185. |
| 25 |
3853056 |
BEARING, Main, center, upper, 0.002 in. U.S. This part replaces 0914186. |
| 25 |
3853058 |
BEARING, Main, center, upper, 0.020 in. U.S. This part replaces 0914188. |
| 25 |
3853059 |
BEARING, Main, center, upper, 0.030 in. U.S. This part replaces 0914189. |
| 25 |
3858945 |
Bearing Kit This part replaces 0913739. |
| 25 |
3858946 |
Main Brg Kit .010 This part replaces 0914187. |
| 26 |
3852781 |
BEARING, Center, standard This part replaces 0913721. |
| 26 |
3853019 |
BEARING, Center, 0.015 in. U.S. This part replaces 0914146. |
| 27 |
3852782 |
BEARING, Rear, standard This part replaces 0913722. |
| 27 |
3853020 |
BEARING, Rear, 0.015 in. U.S. This part replaces 0914147. |
| 28 |
3852783 |
BEARING, Front intermediate, std. This part replaces 0913723. |
| 28 |
3853022 |
BEARING, Front intermediate, 0.015 in. U.S. This part replaces 0914149. |
| 29 |
3852784 |
BEARING, Rear intermediate, std. This part replaces 0913724. |
| 29 |
3853023 |
BEARING, Rear intermediate, 0.015 in. U.S. This part replaces 0914150. |
| 30 |
3852780 |
BEARING, Front, standard This part replaces 0913720. |
| 30 |
3853018 |
BEARING, Front, 0.015 in. U.S. This part replaces 0914145. |
| 31 |
3852791 |
BOLT, Eccentric This part replaces 0913731. |
| 32 |
3852794 |
SPROCKET, Crankshaft This part replaces 0913734. |
| 33 |
3852795 |
KEY, Sprocket This part replaces 0913735. |
| 34 |
3852790 |
WASHER, Camshaft sprocket This part replaces 0913730. |
| 35 |
3852785 |
SPROCKET, Camshaft This part replaces 0913725. |
| 36 |
3852786 |
DOWEL PIN This part replaces 0913726. |
| 37 |
3852805 |
OIL SEAL, Rear This part replaces 0913745. |
| 38 |
3853905 |
DAMPER, Crankshaft This part replaces 0986096. |
| 39 |
3853021 |
BOLT, Damper This part replaces 0914148. |
| 40 |
3852673 |
ECCENTRIC, Fuel pump, outer This part replaces 0913176. |
| 41 |
3852789 |
ECCENTRIC, Fuel pump, inner This part replaces 0913729. |
| 42 |
3853903 |
CHAIN, Timing This part replaces 0986094. |
| 43 |
3852788 |
BOLT, Oil pump to block This part replaces 0913728. |
| 44 |
3852787 |
PLATE, Standard This part replaces 0913727. |
| 44 |
3853024 |
PLATE, 0.002 in. O.S. This part replaces 0914151. |
| 44 |
3853025 |
PLATE, 0.004 in. O.S. This part replaces 0914152. |
| 45 |
3852768 |
POINTER, Timing This part replaces 0913706. |
| 46 |
0914974 |
BRACKET, Oil pressure |
| 47 |
3853953 |
FLYWHEEL This part replaces 0986304. |
| 48 |
3852804 |
RING GEAR, Flywheel This part replaces 0913744. |
| 49 |
3853827 |
OIL SEAL, Front cover This part replaces 0984884. |
| 50 |
3853078 |
CLAMP, Distributor This part replaces 0914208. |
| 51 |
3853077 |
SCREW & WASHER, Clamp This part replaces 0914207. |
| 52 |
3853273 |
LOCKNUT, Coupler This part replaces 0914565. |
| 53 |
0987069 |
LINE, Oil |
| 54 |
3853862 |
COUPLING, Flywheel This part replaces 0985727. |
| 55 |
3853274 |
STUD, Coupler This part replaces 0914566. |
| 56 |
3853003 |
COVER, Flywheel This part replaces 0914078. |
| 57 |
0502900 |
OIL FILTER This part replaces 0173231. |
| 58 |
3852421 |
SCREW, Baffle This part replaces 0907768. |
| 59 |
0379957 |
PETCHOCK ASSY, Water drain |
| 60 |
0980634 |
PULLEY, Crankshaft |
| 61 |
3853800 |
OIL PRESSURE SENDER This part replaces 0982650. |
| 62 |
3852767 |
GASKET, Front cover This part replaces 0913705. |
| 63 |
3853011 |
BOLT, Front cover, 2 in. This part replaces 0914137. |
| 63 |
3853012 |
BOLT, Cover to block, 1 3/4 in. This part replaces 0914138. |
| 63 |
3853013 |
BOLT, Front cover, 2 1/4 in. This part replaces 0914139. |
| 63 |
3853014 |
BOLT, Front cover, 2 1/2 in. This part replaces 0914140. |
| 64 |
3853075 |
WASHER, Damper This part replaces 0914205. |
| 65 |
3853325 |
SCREW, Clamp to engine This part replaces 0914761. |
| 67 |
3853035 |
INSERT, Oil filter This part replaces 0914165. |
| 68 |
0379948 |
SCREW, Retainer to adapter |
| 70 |
250001016 |
Hex Flanged Screw M8 X 25 S.Grip |
| 80 |
233261434 |
Flanged Elastic Nut M6 |
| 100 |
293200168 |
Oil Seal |
| 110 |
293350153 |
Ball Bearing |
| 120 |
504152576 |
Circlip |
| 130 |
504152628 |
Shim |
| 140 |
504153910 |
Sprocket 21 Teeth |
| 150b |
293350142 |
Ball Bearing |
| 150c2 |
504154043 |
Cap |
| 150d |
293300291 |
O-Ring Seal This part replaces 293300230. |
| 280 |
504152784 |
Spring Washer M10 |
| 290 |
207503046 |
Hex. Flange Screw M10 X 30, Scotch Grip |
| 1100 |
293200159 |
Oil Seal |
| 1120 |
504152582 |
Circlip |
| 1130 |
504153996 |
Sprocket 49 Teeth |
| 1140 |
504152572 |
Circlip |
| 1500 |
504153393 |
Drive Chain, 114 Links |
| 1510 |
414575600 |
Hair Pin |
| 1520 |
504153760 |
Adjustment Screw |
| 1540 |
250500013 |
Hex. Countersunk Drain Plug |
| 1545 |
250500013 |
Hex. Countersunk Drain Plug |
| 1550 |
293300202 |
O-Ring |
| 1600 |
504154577 |
Chain Tensioner |
| 1610 |
504153312 |
Chain Slider |
| 1650 |
293370105 |
Circlip |
| 1690 |
250000764 |
Hex. Button Head Screw M8 X 1.25 X 35 |
| 1700d |
515179692 |
Clip Connector |
| 1700f |
415130141 |
Sleeve |
| 1710 |
293300200 |
O-Ring |
| 1720 |
250001153 |
Flanged Hex. Screw M6X20 |
| 1740a |
504152930 |
Cap This part replaces 504154304. |
| 1740b |
293710180 |
Straight Pipe Fitting |
| 1740c |
219704539 |
Hose 5.7MM - 630MM |
| 1790 |
250001015 |
Flanged Hex. Screw M6 X 35 |
| 2030 |
293300201 |
O-Ring |
| 2040 |
504154043 |
Cap |
| 2050 |
504152572 |
Circlip |
| 2500b |
250300028 |
Clinch Stud, M8 X 25 |
| 2510 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 3000b |
XXX |
Not Available As Spare Parts |
| 3000c |
XXX |
Not Available As Spare Parts |
| 3000d |
504154417 |
Retaining Ring |
| 3000f |
293350059 |
Ball Bearing |
| 3000g |
293300291 |
O-Ring Seal This part replaces 293300230. |
| 3200a |
415130661 |
Clip |
| 3200b |
504152651 |
Cleat |
| 4000 |
250000764 |
Hex. Button Head Screw M8 X 1.25 X 35 |
